The added value of chemical shift imaging in evaluation of bone marrow changes in sickle cell disease

Abstract

Background

The aim of this study was to assess the added value of chemical shift imaging when used with routine MRI study in evaluation of bone marrow changes in SCD. Forty-two patients with SCD and bone pain were included in the study; they underwent CSI and routine MRI study on the symptomatic anatomic part of the skeleton.

Results

Four patterns of diffuse bone marrow changes were recognized; they varied from persistent red marrow to diffuse hypointense patterns with abnormal signal loss percentage on CSI that suggest presence of iron overload (n = 28, 66.6%). Serum ferritin level was increasing in accordance to the degree of signal changes found on CSI with significant high negative correlation between the percentage of signal loss on CSI obtained from IP-OP/IP formula and serum ferritin level. In focal marrow lesions, all T1 hyperintense lesions demonstrated corresponding hyperintensity on IP and OP; the detection frequency on CSI was relatively higher on OP compared with IP images.

Conclusion

CSI has high diagnostic performance in detecting diffuse marrow changes and development of iron overload in SCD. In SCD-related focal marrow lesions, CSI could have a complementary role in detection of T1 hyperintensity and lesion conspicuity.

Background

Sickle cell disease (SCD) is one of the hemoglobinopathies that is characterized by abnormal production of hemoglobin, repeated cycles of sickling and unsickling, stasis and sequestration of blood cells, vascular obstruction, red cell destruction, hemolytic anemia, and bone marrow hyperplasia. SCD can result in persistence of hematopoietic (red) marrow within the appendicular skeleton; moreover, it can cause various skeletal problems that include osteomyelitis and progressive bone infarctions which may occur anywhere in the skeleton and are the source of painful bone crises [1, 2].

As blood transfusion has a prominent role in patient’s management in SCD, there is an increased risk of development of significant iron overload and subsequent iron-related complications to many organs [3].

Magnetic resonance imaging (MRI) is the most effective imaging tool used to evaluate focal bone marrow abnormalities as well as transfusion-related iron overload in a noninvasive way. Iron overload detection on MRI could be attributed to the susceptibility effect of iron which produces loss of signals in the involved tissues; the most common utilized sequence is the T2*-weighted sequence. Dual-sequence T1 gradient in-phase (IP) and out-of-phase (OP) imaging (a.k.a. chemical shift imaging (CSI)) can be used in the same manner to evaluate iron overload. Being characterized by higher echo time than the OP images, the IP images are more sensitive to iron deposition because of its T2* effect, this in turn explains why signal intensity reduction of iron-overloaded marrow is observed on IP not OP images [4, 5].

Aim of the work

The aim of this study was to assess the added value of chemical shift imaging when used with the routine MRI study in evaluation of bone marrow changes in sickle cell disease.

Methods

This observational analytic prospective study was conducted from February 2019 through December 2019 after being ethically approved by the institution committee.

Study participants

This study included forty two (twenty males and twenty-two females) patients known to have SCD. All patients were complaining of bone pain when they were referred from the emergency room and/or orthopedic department to the MRI unit. They underwent chemical shift imaging (T1-weighted dual gradient-echo in-phase and out-of-phase sequence) which was included within the routine MRI study on the symptomatic anatomic part of the skeleton. All the patients underwent complete clinical examination, CBC, differential white blood cell count, inflammatory markers, serum ferritin, and renal function tests. Informed written consent was obtained from all patients prior to study.

Inclusion criteria

In patients diagnosed with SCD, the inclusion criteria were based acute bone pain and chronic persistent bone pain with a clinical concern of osteomyelitis.

Exclusion criteria

Skeletal trauma and musculoskeletal pathologies other than SCD were the exclusion criteria.

CSI and MRI techniques

All MRI studies were performed on a 1.5-T Achieva; Philips (Netherlands) closed MRI machine and using appropriate surface receiver coils.

At least, the following sequences were performed in all studies:

  1. 1-

    Fat-suppressed fluid-sensitive sequence using either short tau inversion recovery STIR (TR/TE 6580/102, TI 130) or TSE T2-fs (TR/TE 4200/92 frequency selective fat saturation) or TSE PD-fs (TR/TE 7650/34 frequency selective fat saturation).

  2. 2-

    Pre-contrast T1-fs sequence (TR/TE 883/23, frequency selective fat saturation).

  3. 3-

    T1-weighted dual gradient-echo in-phase and out-of-phase sequence in axial and/or coronal planes (TR/TEs, 7/4.8 and 2.4).

  4. 4-

    Post-contrast T1-fs sequence (TR/TE 883/23), in more than one plane, in case of absence of T1 hyperintensity on pre-contrast images and after ensuring that the renal function is normal. 0.2 ml/kg body weight Magnevist (Schering, Germany) was used.

Image analysis

Three observers with 13, 6, and 5 years of experience interpreted the images independently. For diffuse marrow signal alteration, the IP and OP images were simultaneously analyzed for signal intensity; equal-sized region of interest (ROI) with equal number of pixels were placed over the same area of normal-appearing bone marrow (i.e., lacking any focal lesions) on the IP and the corresponding OP images. In order to perform an accurate measurement, the entire sequences were carefully scrutinized to avoid placement of the ROI cursors over any focal marrow abnormality, and the selected position for ROI placement was targeted on an area that did not attain any hyperintensity on STIR and/or T1WI. Computation of the percentage of signal loss on CSI was then obtained from IP-OP/IP formula; the result was considered abnormal when the value was < 20%, absent, or shows negative value.

For focal bone marrow lesions whether osteonecrosis or osteomyelitis, the STIR sequence together with the pre- and post-contrast-enhanced T1-fs and CSI images were scrutinized for number, location, and signal characteristics of signal abnormality areas within the bone marrow and/or the overlying soft tissues.

The frequency of detection of marrow focal lesions was recorded across different study sequences in order to assess the value of IP and OP images in focal marrow abnormality detection.

Statistical analysis

Results of CSI were recorded and tabulated. The statistical analysis was done using SPSS-16, and the descriptive data were represented as number and percent. Comparison between serum ferritin levels across different patterns of diffuse bone marrow signal changes was done by ANOVA test. Correlation between serum ferritin level and the percentage of bone marrow signal loss on CSI was done and represented as a scatterplot. Inter-rater agreement was assessed for focal bone marrow abnormalities.

Results

Twenty males (47.6%) and twenty-two females (52.4%) who complained of bone pain were included in the study; their mean age was 26.95 ± 9.1 years (range 8–45 years). Thirty-five patients presented with acute bone pain, whereas seven patients had chronic bone pain.

Diffuse marrow abnormality findings

There were four different patterns of diffuse bone marrow signal changes among all patients; they were (1) persistent red marrow with normal CSI percentage of signal loss (> 20%) which suggest normal iron load, (2) diffuse abnormal hypointense patterns with either inadequate (< 20%) signal loss on OP, (3) diffuse abnormal hypointense patterns with no signal loss or signal reversal on OP (OP > IP), and (4) diffuse signal void pattern on all sequences including IP and OP images. The patterns from 2 to 4 were suggestive of iron overload. Almost two-thirds of patients (n = 28, 66.6%) had diffuse bone marrow signal abnormalities that suggest presence of iron overload; most of them (19 patients {~ 45.23%}) showed lack of any signal loss on OP images (Table 1, Fig. 1).

Table 1 Diffuse bone marrow changes in SCD (n = 42)
Fig. 1
figure1

Axial IP with corresponding OP images in three different patients with SCD and elevated serum ferritin; a and b show inadequate signal loss on OP images < 20%, (IP-OP/IP = 12%), c and d show lack of normal signal loss with reversal of normal signal characteristics of CSI in a different patient, OP > IP, (IP-OP/IP = − 32%), e and f show signal void pattern with diffuse very low signal on both IP and OP images

Of the total, 30 patients (71.4%) have a history of previous blood transfusions; however, no one was on chronic blood transfusion regimen nor had blood transfusion in the previous 2 months. Various ranges of serum ferritin level were found across different patterns of diffuse marrow changes; their means were increasing in accordance to the grade of marrow changes and the degree of signal changes found on CSI with statistically significant difference (Table 2)

Table 2 Serum ferritin level across different patterns of diffuse marrow changes

On correlation analysis, there was significant high negative correlation between the percentage of signal loss on CSI obtained from IP-OP/IP formula and serum ferritin level (Fig. 2).

Fig. 2
figure2

Correlation scatterplot, expressed in a logarithmic scale, demonstrates significant high negative correlation between the serum ferritin level and the percentage of signal loss on CSI

Focal marrow abnormality findings

Among all patients, there were 34 patients who had one or more focal marrow lesion with signal characteristics compatible with osteonecrosis (total number of lesions was 153); other 4 patients showed a focus of osteomyelitis (total number of lesions was 4). Final diagnostic confirmation for all lesions was based mainly on response to specific therapy and long-term follow-up. Bone biopsy confirmed all cases with osteomyelitis; this was performed surgically in two cases who underwent debridement, and by ultrasonographic-guided aspiration of subperiosteal and peri-osseous abscess in the two other cases.

The most common involved anatomic location by osteonecrosis was the femur notably the femoral head then the pelvic bones (Table 3, Fig. 3).

Table 3 Location of focal signal abnormality marrow lesions (number of cases = 38/42, ~ 90.5%)
Fig. 3
figure3

Coronal IP (a) and OP (b) with axial T1fs (c & d) in 27 year-old female patient with bilateral acute pelvic bone pain, show diffuse persistent red marrow with normal percentage of signal loss on OP (IP-OP/IP = 23 %), note the patient had diffuse low signals on T1 (not shown). (c & d) show multi-focal T1 hyperintensity in the sacrum, pelvic bone, left acetabulum and left femoral head consistent with acute osteonecrosis, note corresponding sacral hyperintensity on IP and OP (stars)

T1 hyperintensity on fat-suppressed T1 was diagnostic for osteonecrosis in acute pain setting; this was observed in 22 patients with total number of lesions was 83 lesions. Among the remaining 12 patients, 9 patients underwent post-contrast study and showed marginal enhancement of their focal marrow signal abnormalities (total number of lesions was 61); the imaging criteria for diagnosis of osteonecrosis in such cases were the presence of marginal enhancement, no patchy enhancement, no extra-osseous signal abnormality, no cortical defects and absent sequestration; final confirmed diagnosis was based on therapeutic response and long-term follow-up. The constant imaging feature in osteomyelitis lesions was the extra-osseous involvement and patchy enhancement (Table 4, Fig. 4).

Table 4 Imaging features of focal signal abnormality marrow lesions (number of cases = 38/42, ~ 90.5%)
Fig. 4
figure4

Axial non-enhanced T1fs a and b through the lower femurs in 19-year-old male patient with bilateral acute thigh pain show bilateral focal bone marrow hyperintensity involving the right more than the left lower femoral shaft; features of acute marrow infarcts. Axial OP c and post-contrast T1fs d through the right upper tibial shaft on the same patient show focal intra-medullary hypointense sequestrum (yellow arrow), focal cortical interruption (red arrow), and non-homogenous marrow enhancement (blue arrows); features are consistent with chronic osteomyelitis

Regarding CSI in focal marrow lesions, all T1 hyperintense lesions (83 lesions ~ 54.2%) demonstrated corresponding high signals on both IP and OP images. The frequency of focal marrow abnormality detection on CSI that attained STIR hyperintensity was relatively higher on OP compared with IP images (Table 5).

Table 5 Frequency of focal marrow abnormality detection by CSI (n. of lesions = 157)

Inter-rater reliability

The percent agreement for focal marrow abnormalities was high; it was 98% for STIR high signal, 97% for OP signal abnormality, 95% for T1 hyperintensity, and 91% for IP images.

Discussion

Either diffuse or focal, bone marrow complications of SCD are common; they are related to chronic hemolysis, repeated blood transfusion, or vaso-occlusion [6].

Iron is toxic to bone marrow cells; it can be overloaded within the bone marrow in SCD especially in repeated blood transfusion. The toxicity of iron is accentuated by the effect of reactive oxygen species and hydroxyl radical leading to significant oxidant damage to the bone marrow cells and eventual ineffective erythropoiesis phenotype; the presence of such phenotype favors the development of iron cardiomyopathy; thus, the detection of iron overload in SCD is crucial [7, 8].

MRI has been utilized for non-invasive detection of iron overload in different tissue particularly the liver and the heart. The most simple and widely available method is the liver-to-muscle signal intensity ratio which is based on iron-induced T2* shortening. The current study utilized the same idea but on a different sequence; it depended on the hypothesis stated that the signal intensity decrease observed on IP images, compared with OP images, is related to iron-induced magnetic susceptibility and T2* shortening. And this is the novel point in the study, as there is no known report that studied marrow iron overload using CSI [6, 9, 10].

Among different patterns of diffuse marrow signal changes found in the present study, 2/3 of the patients showed evidence of iron overload in the form of abnormal percentage of signal loss (< 20%) on OP that was negatively correlated with serum ferritin level. This finding highlights the diagnostic use of CSI in iron detection in patients with SCD and could emphasize the value of adding such sequence to the routine skeletal MRI in SCD. Although a few reports studied the role of MRI in detecting bone marrow abnormality in hemoglobinopathy-related hemosiderosis, there is a paucity of studies concerning with the role of CSI in detection of iron overload in bone marrow or other tissues. Drakonaki et al. [11] studied multiple MRI sequences including T1-w Gradient Echo (GRE) in assessment of bone marrow changes in beta-thalassemia and their relation to serum ferritin. They found diffuse marrow hypointensity in T1-w GRE with decreased bone marrow to paraspinous muscle signal intensity ratios in 23/40 patients (57.5%) along with significant negative correlation with mean ferritin values (r = − 0.610, p = 0.01). Although Drakonaki et al. [12] did not utilize CSI in their evaluation, the used T1-w GRE with its echo time (TE: 4) is the same utilized in IP images in the current study; thus, it resembles IP images in its T2* effect and subsequently its capability of detecting iron overload. Furthermore, Westphalen et al. [13] studied the role of opposed-phase MRI in hepatic iron deposition; they found that in patients with hepatic iron deposition there was significant signal intensity loss on the IP images; however, they did not utilize the OP images in their evaluation nor correlate it with the serum ferritin level as the current study did [14, 15].

Regarding focal marrow lesions in the current study, the IP and OP images demonstrated high signal intensity in all cases of acute osteonecrosis that showed hyperintensity on T1fs images. This finding would be expected as both CSI and T1fs are T1 weighted; the ability of CSI to accurately detect T1 hyperintensity might extend its utility in SCD-related marrow abnormality especially if the T1fs suffered from artifact due to magnetic field inhomogeneity that commonly occurred on closed MR scanners, or there was lack of T1fs sequence for any reason such as in case of utilization of low field MRI [5].

The frequency of focal marrow abnormality detection on CSI that attained STIR hyperintensity was relatively higher on OP compared with IP images. Although this feature appears to have a little value especially if it stands alone against the ability of STIR in documentation of marrow edema-like lesions, it might bear the OP images a complementary role in lesion size detection, as lesion conspicuity is generally accentuated on OP images due to peripheral signal loss termed “India ink artifact” which is produced along the borders between fat and non-fatty tissue [16, 17].

Conclusion

CSI has high diagnostic performance in detecting diffuse marrow changes and development of iron overload in SCD. In SCD-related focal marrow lesions, CSI could have a complementary role in detection of T1 hyperintensity and lesion conspicuity.
