The value of the added diffusion-weighted images to multiparametric MRI in the early diagnosis of uterine cervix cancers and nodal assessment
Egyptian Journal of Radiology and Nuclear Medicine volume 52, Article number: 43 (2021)
Cervical cancer still one of the most common causes of tumor-related death in developing countries presented in younger women. In this study, we aimed to evaluate the value of diffusion-weighted MRI in early diagnosis of malignant cervical lesions, to assess metastatic adenopathy, peritoneal dissemination, and possible tumor recurrence, and determine treatment response. This study included 60 patients with abnormal vaginal bleeding and suspected cervical lesion by US. A histopathological biopsy was done. Pelvic MR with DWI and dynamic contrast-enhanced MRI were done for all patients.
According to the histopathological findings, we divided our studied 60 patents into two groups: group I, malignant lesions (46 lesions; 76.7%), and group II, benign lesions (14 lesions; 23.3%). Multiparametric MRI could detect all cervical lesions but with poor pathologic characterization, achieving 72.37% sensitivity, 37.50% specificity, 63.33% accuracy, 76.19% PPV, and 33.33% NPV. When compared with DWI with ADC value measurements at high b value (b = 800) to MRI exam, it showed a higher diagnostic accuracy with good lesion pathological characterization that achieved 95.65% sensitivity, 71.43% specificity, 90% accuracy, 91.67 PPV, and 83.33% NPV. The mean ADC value for malignant lesions was 0.86–1.1, mean = 0.92 ± 0.71 × 10−3 mm2/s, while the mean ADC value in the benign lesion group was 1.18 ± 0.1 × 10–3 mm2/s.
Comparing DWI with ADC values measurements at high b value to the multiparametric MRI examination of the female pelvis increases the sensitivity, specificity, and diagnostic accuracy of characterization and early diagnosis of cervical malignant focal lesions and reduces the need for intravenous contrast administration.
Cervical carcinoma is a common gynecological tumor still representing important cause of tumor-related death in younger females in developing countries . The incidence rate of cervical cancer in Egypt is 6.6 cases/100,000 populations, while prevalence of pre-invasive high-grade lesions represents 0.3%among the Egyptian females . MRI could identify the anatomic origin, shape, and composition of uterine cervical masses, so a definitive diagnosis can be reached [3,4,5]. DW-MR imaging is a functional imaging technique whose contrast derives from the random motion of water molecules within tissues that allow its use in abdominal and pelvic applications . DWI when combined with multiparametric MRI becomes a complementary diagnostic tool for the diagnosis of uterine lesions giving more information for the differentiation and extension of benign and malignant lesions [7, 8]. DWI is not only helpful in differentiating benign from malignant lesions but also it can be used to assess metastatic adenopathy, peritoneal dissemination, and possible tumor recurrence and determine treatment response .
This study aimed to evaluate the value of diffusion-weighted MRI in early diagnosis of malignant cervical lesions.
This study included 60 patients with history of vaginal bleedings and suspicious cervical focal lesions by ultrasound examination. The patient’s age ranged from 37 to 63 years with mean age ± 44.6 years. Ethics committee approvals in addition to informed written consent were obtained from all included patients.
Patients with clinical history of abnormal vaginal bleedings with suspicious transvaginal ultrasound findings of uterine cervix focal lesion were included. The patient did not receive any treatment prior to the examination.
Patients unfit for MRI examination (e.g., who had cardiac pacemakers/prosthetic heart valves, cochlear implants, or other metallic implants) or having a history of claustrophobia or those who could not tolerate MRI exam were excluded.
MR imaging was performed on a 1.5-T scanner (Achieva, Philips Medical System) using pelvic phased-array Torso coil with the patient in the supine position. Intravenous administration of an antispasmodic drug (10 mg of [Visceralgine; Organon, Livron, France]) was given immediately before MR imaging to reduce bowel peristalsis. All cases were asked to check their renal function (creatinine level) before the examination.
MR imaging protocol inclusion
The MR imaging protocol included the following:
Non contrast MRI images, axial T1-weighted (TR/TE, 500/10 ms), axial T2-weighted (TR/TE, 3300/100 ms), slice thickness 6 mm, gap 1 mm, and FOV 32–42 cm. Matrix 256 × 256. Coronal and sagittal T2-weighted, slice thickness 8–10 mm, gap 1 mm, and FOV 40–50 cm. Matrix 256 × 256.
Gadopentetate dimeglumine contrast (Magnevist; Schering, Berlin, and Germany) was administered intravenously at weight-based dosing of 0.1 ml/kg body weight with a bolus injection rate of 2 ml/s by an automatic injector, followed by a 20 mL normal saline flushing the tube. Post-contrast T1 fat sat THRIVE (high-resolution isotropic volume examination) images were acquired instantly after administration of gadolinium. Images were acquired serially at 0, 30, 60, 90, and 120 s.
DW-MRI: using a spin echo single-shot sequence with free-breathing, with TR 2.8 s, TE 72, matrix 512 × 512, slice-thickness 3 mm with an inter-slice gap of 1 mm, and FOV of 350 mm, and b-factor of 0, 300, and 800 s/mm2 on an axial plane for each patient prior to contrast administration. The ADC maps were automatically generated for all DW images, and ADC values were measured at b value 1000 s/mm2. The mean ADC value was measured by placing ROI of average 1–2 cm in the solid part of the lesion and expressed in 10−3 mm2/s.
The histopathological results were used as a gold stander reference for all lesions and correlated to the imaging findings.
All statistical calculations were done using the SPSS test for calculation of mean, standard deviation, frequencies, and percentages. Sensitivity, specificity, accuracy, positive predictive value, and negative predictive value for MRI and DWI were calculated separately for each parameter.
Two radiologists with 10 and 5 years’ experience in gynecological MR imaging independently assessed cervical lesions of pelvic MRI examination with no available histopathological data. MRI imaging was evaluated for the following: the site, size, and extension of the cervical focal lesion, pattern of enhancement, infiltration of the related structures, and presence or absence of pelvic lymph nodes.
In the studied 60 suspicious uterine cervix focal lesions, the majority (21 patients) were complaining of abnormal vaginal bleeding, usually post-coital. Malodorous discharge and vaginal discomfort were reported in the remaining 9 patients. The patient’s age ranged from 39 to 63 years with a mean age ± 44.6 years.
Histopathological results of studied 60 patients
According to the histopathological findings, we divided our studied 60 patients into two groups: group I, malignant lesions group (46 cases; 76.7%), and group II, benign lesions (14 cases; 23.3%) (Table 1).
Multiparametric MRI results in all studied uterine cervix focal lesions (number = 60 cases)
Fifty-four lesions out of the studied 60 focal lesions of the uterine cervix found showed iso- to hypointense signals on T1WI and exhibited moderate hyper-intense signal on T2WI regardless of benign or malignant etiology. In the remaining 6 lesions, 4 of them were diagnosed as chronic cervicitis with nabothian cyst that showed iso- to low signal on T1WI and mixed intermediate-high signals in T2WI, and the remaining 2 cervical lesions were diagnosed to be degenerated leiomyoma which exhibits low signals on T1WI and mixed signals on T2WI (Table 2).
DW-MRI with ADC value measurement results of group I: malignant uterine cervix focal lesions (number = 46)
All studied malignant uterine cervix focal lesions (46 lesions) showed restricted diffusion on DW-MRI (diffusion positive) being of hyper-intense signals at DWI with persistent high signals at high b value (b = 800) and corresponding low signal intensity at ADC map images. The ADC value of studied malignant endometrial lesions showed relatively low value averages of 0.86–1.15 × 10-3 mm2/s with mean ADC value of about 0.92 ± 0.71 × 10−3 mm2/s (Table 3) (Figs. 1 and 2).
DW-MRI with ADC value measurement results in group II: benign uterine cervix focal lesions (number = 14)
Out of the studied 14 benign uterine lesions, 8 lesions which proved to be cervical polyps were diffusion negative in the form of low signals in DWI with high signals in low b value that fade out in high b value(b = 800) with relatively high ADC value that ranged from 1.37 to 1.64 × 10−3 mm2/s with a mean ADC value of about 1.4 ± 0.31 × 10−3 mm2/s, while the 4 chronic cervicitis lesions with nabothian cyst showed mixed diffusion changes in the form of mild diffusion restriction with facilitated cystic areas, with ADC value ranging from 1.2 to 1.8 × 10−3 mm2/s and with mean ADC value of about 1.5 ± 0.31 × 10-3 mm2/s and 2 uterine cervices degenerated fibroid that showed mixed diffusion changes evidenced as low signal with hyperintense foci in DWI and mixed low and high signals at ADC map, with ADC values 0.86 × 10−3 mm2/s. The ADC value of 5/7 benign focal lesions showed relatively high values that ranged from 1.57 to 2.4 × 10−3 mm2/s with a mean ADC value of about 1.7 ± 0.31 × 10−3 mm2/s with exception of 4 cervicitis with nabothian cyst and 2 degenerated fibroid that showed low ADC values which ranged from 0.86 to 1.2 × 10−3 mm2/s with a mean ADC value of about 0.1 ± 0.19 (Table 4) (Fig. 3).
The utility of DW-MRI versus multiparametric MRI in the characterization of the studied 60 uterine cervix focal lesions
The current study revealed that multiparametric MRI could detect all cervical focal lesions but with poor pathological characterization as most lesions (44/60) exhibit iso- to low signals at T1WI with intermediate-high signals at T2WI, and the remaining 16 lesions exhibit heterogeneous signals at both T1 and T2WI and post-contrast variable degree of enhancement achieving 72.37% sensitivity, 37.50% specificity, 63.33% accuracy, 76.19% PPV, and 33.33% NPV. When adding DWI with ADC value to MRI at high b value (b = 800), it showed a higher diagnostic accuracy with good lesion pathological characterization that achieved 95.65% sensitivity, 71.43% specificity, 90% accuracy, 91.67 PPV, and 83.33% NPV (Table 5).
The presence of lymph node metastasis in the pelvic cavity was evaluated. Metastatic lymphadenopathy was defined as any enlarged lymph nodes larger than 10 mm in the short-axis diameter on T1-weighted images  (Fig. 4).
The new 2018 FIGO system promotes the value of imaging modalities especially MRI imaging to increase the accuracy of tumor staging and guide treatment/monitoring. DWI increases the staging accuracy of MRI by permitting better evaluation of tumor size, extra uterine extension, and nodal infiltration, factors that affect treatment selection and planning [11,12,13].
In this study, the age of the included patients with suspected cervical cancers ranged from 39 to 63 years, M = ± 44.6 years. The abnormal vaginal bleeding was the main complaint in 42 patients while 18 patients complained of malodorous discharge and vaginal discomfort. This was in agreement with Sherif HA et al., who studied 20 female patients age 30–75 years with a clinical picture of abnormal vaginal bleeding and vaginal discharge , and also with Rezvani M et al. who stated that cancer cervix typically presents in younger women with an average age around 45 years, presented by abnormal vaginal bleeding, discomfort, and malodorous discharge as the first complaints .
We classified the studies 60 cases according to the histopathological results into 2 groups: 46 malignant lesions (group 1), 34 squamous cell carcinoma lesions, 8 adenocarcinomas, and 4 undifferentiated carcinoma and 14 benign lesions (group 2), 8 cervical polyps, 4 chronic cervicitis with nabothian cysts, and 2 fibroid lesions.
Our findings were in coincidence with that of Mahmoud SM et al., who found that the pathology of the included cases was sq. cell carcinoma in 72%, adenocarcinoma in 12%, sarcomatoid cervical carcinoma in 4%, spindle cell tumor in 4%, basaloid carcinoma in 4%, and undifferentiated carcinoma in 4 %, and with Dashottar S et al., who reported that out of the studied 35 cases, 33 (94.3%) were sq. cell carcinoma, 1 (2.9%) was papillary adenocarcinoma, and 1 (2.9%) was small cell carcinoma . However, Sherif HA et al. found that the histopathological diagnosis revealed adenocarcinoma in 4 cases (20%), squamous cell carcinoma in 15 cases (75%), and chronic cervicitis in 1 case (5%) .
MR imaging represents the most valuable imaging modality for the detection of the primary tumor, nodal involvement, and local spread. It is also the best modality for showing recurrent disease and monitoring therapeutic response .
In the present work, the imaging findings revealed poor MRI signal characterization of pathologically proved different lesions as 27/30 cervical lesions showed iso- to hypointense signals on T1WI and moderate hyper-intense signals on T2WI with variable contrast enhancement regardless of benign or malignant etiology; however, 6 lesions (4 chronic cervicitis with nabothian cyst and 2 degenerated leiomyoma) showed iso- to low signal on T1WI and mixed/intermediate-high signals in T2WI.
Our findings were in concordance with Yoshikazu O who stated that some tumors or tumor-like lesions can show similar MR imaging findings, such as adenocarcinoma, adenoma malignum, and florid endocervical hyperplasia . However, Mahmoud SA found that hypointense T1 signal was seen in 34/70 (48.5%) cases, isointense signal in 28/70 (40%) cases, hyperintense T1 signal in 6/70 (8.5%) cases, and heterogeneous signal intensity in 2/70 (2.8%). T2WIs showed a hyperintense signal in 62/70 (88%) cases and intermediate signal in 2/70 (2.8%) cases and heterogeneous signal intensity in 6/70 (8.5%) . Tamai KT et al. found that degenerated leiomyomas (7 lesions) showed low SI on T1-weighted images with areas of high SI on T2-weighted images . Patel et al. reported that cervical tumors tend to give iso- to high signal compared to cervical stroma on T2WI .
The diffusion-weighted image (DWI) visualizes the local microstructural characteristics of water diffusion. High intensity on DWI with low apparent diffusion coefficients (ADC) is suggestive for malignant polyp with hypercellular nature, whereas benign polyps tend to show higher ADC value . Our results revealed that all studied malignant cervical focal lesions (n = 46) showed positive diffusion restriction at high b value (b = 800) with relatively low ADC values that ranged from 0.86 to 1.15 × 10−3 mm2/s, M = 0.92 ± 0.71 × 10−3 mm2/s, while 8/14 benign cervical lesions were diffusion negative in high b value (b = 800) and 3 lesions (4 ch. cervicitis with nabothian cyst and 2 degenerated fibroid) showed mixed diffusion changes. The ADC value of 10/14 benign focal lesions were relatively high that ranged from 1.57 to 2.4 × 10−3 mm2/s (M = 1.7 ± 0.31 × 10−3 mm2/s); however, atypical lesions (chronic cervicitis with nabothian cyst and degenerated fibroid) showed low ADC values that ranged from 0.86 to 1.2 × 10−3 mm2/s (M = 0.1 ± 0.19). This is may be attributed to the presence of necrosis and focal signal intensity changes as well as susceptibility artifacts. These result findings matched with many other studies which concluded the reported mean ADC values for both squamous cell carcinoma and adenocarcinoma cases to be less than 1 × 10−3 mm2/s, averaging 0.88–0.91 × 10−3 mm2/s, 0.8827 × 10−3 mm2/s, and 0.72 ± 0.168 × 10−3 mm2/s, respectively [23,24,25]. Also, Mahmoud SA concluded that in the present study, the mean ADC value for malignant lesions was 0.82 × 10−3 ± 0.1 SD mm2/s , and Sherif HA et al. stated that the mean ADC value of cervical carcinoma in our study was 0.82 × 10−3 mm2/s .
According to these study results, multiparametric MRI could detect all cervical focal lesions but with poor pathological characterization, achieving 72.37% sensitivity, 37.50% specificity, 63.33% accuracy, 76.19% PPV, and 33.33% NPV. When adding DWI with ADC value measurements at high b value (b = 800) to MRI exam, it showed a higher diagnostic accuracy with good lesion pathological characterization that achieved 95.65% sensitivity, 71.43% specificity, 90% accuracy, 91.67 PPV, and 83.33% NPV. Our results matched with Mahmoud SA et al. results which revealed that DWI-MRI showed sensitivity 100%, specificity 50%, accuracy 97%, PPV 97%, and NPV 100%, and the low percentage of the specificity in this study was due to the low number of true negative patients , and Chen et al. found that the sensitivity and specificity of DW-MRI for tumor detection were 100% and 84.8%, respectively. DWI showed 100% sensitivity, a positive predictive value . Mahmoud SM reported that DW-MRI revealed sensitivity, specificity, PPV, and accuracy of 100%, 50%, 97%, and 97% respectively . Also, Exner M. et al. concluded that the use of DWI led to an increase in sensitivity of infiltrated adjacent tissue (from 86 to 90%) and detection of lymph node metastases (from 47 to 67%) .
The main limitation of this study was the limited sample size. Further studies using a cohort study of patients with long-term follow-up are needed to establish the accuracy of this method for early detection of cervical uterine cancer.
Adding DWI with ADC values measurements at high b value to the multiparametric MRI examination of the female pelvis increases the sensitivity, specificity, and diagnostic accuracy for characterization and early diagnosis of cervical malignant focal lesions and appropriate planning management options.
DWI may replace the contrast study especially for patients not candidates for contrast injection. It can be used in conjunction with ADC values as a standard routine protocol after application in a large number of patients aiming to decrease the diagnostic pitfalls and get higher diagnostic performance including distant metastatic infiltration.
Availability of data and materials
All data generated or analyzed during this study are included in this published article [and its supplementary information files].
Apparent diffusion coefficient
Field of view
Fast spin echo
Magnetic resonance imaging
Negative predictive value
Positive predictive value
Time of echo
Time of repetition
Region of interest
Reinhold C, Gallix BP, Ascher SM (1997) Uterus and cervix. In: Semelka RC, Ascher SM, Reinhold C (eds) MRI of the abdomen and pelvis: a text atlas. Wiley-Liss, New York, pp 585–660
McCarthy S, Hricak H. The uterus and vagina. In:Higgins CB, Hricak H, Helms CA, eds. Magnetic resonance imaging of the body. 3rd ed. New York, NY: Lippincott-Raven, 1997; 761–814.
Bazot M, Darai E, Nassar-Slaba J et al (2008) Value of magnetic resonance imaging for the diagnosis of female pelvis tumors: a review. J Comput Assist Tomogr 32(5):712–723
Sohaib SA, Mills TD, Sahdev A et al (2005) The role of magnetic resonance imaging and ultrasound in patients with adnexal masses. Clin Radiol 60(3):340–348
Solomon D, Breen N, McNeel T (2007) Cervical cancer screening rates in the United States and the potential impact of implementation of screening guidelines. CA Cancer J Clin 57(2):105–111
Rezvani M, Shaaban A (2009) Imaging of cervical pathology. Clin Obstet Gynecol 52(1):94–111
Whittaker C, Coady A, Culver L et al (2009) Diffusion weighted MR Imaging of female pelvic tumors: a pictorial review. Radio Graphics 29(3):759–778
Kuang F, Ren J, Huan Yet al. (2012) Apparent diffusion coefficients of normal uterus in premenopausal women with 3.0-T magnetic resonance imaging. J Comput Assist Tomogr 36(1):54–59
Namimoto T, Awai K, Nakaura T et al (2009) Role of diffusion-weighted imaging in the diagnosis of gynecological diseases. Eur Radiol 19(3):745–760
Perucho JAU, Chiu KWH et al (2020) Diffusion-weighted magnetic resonance imaging of primary cervical cancer in the detection of sub-centimetre metastatic lymph nodes. Cancer Imaging 20:27
Sala E, Rockall A, Rangarajan D et al (2010) The role of dynamic contrast-enhanced and diffusion weighted magnetic resonance imaging in the female pelvis. Eur J Radiol 76(3):367–385
McVeigh PZ, Syed AM, Milosevic M et al (2008) Diffusion-weighted MRI in cervical cancer. Eur Radiol 18(5):1058–1064
Mourad MA-F, Mousa EM (2017) Comparing T2 weighted images/diffusion weighted imaging and T2 weighted images/dynamic contrast enhanced MRI for endometrial carcinoma myometrial invasion. Egypt J Radiol Nuclear Med 48:323–327
Sherif H Abo Gamra, Mohamed G Abdel Mutaleb, Haydar M Sinjawi. (2018) Role of diffusion weighted MRI in diagnosis of cervical cancer. Egypt J Hospital Med 71 (1):2411-2421.
Mahmoud SM, Raafat M (2017) Is there an added role for diffusion weighted imaging in the staging of cervical carcinoma? Egypt J Radiol Nucl Med 48:1131–1139
Dashottar S, Preeth TP, Lohia N (2019) Role of apparent diffusion coefficient as a biomarker in the evaluation of cervical cancer. Indian J Radiol Imaging 29(1):25–32
Dappa E, Elger T, Hasenburg A et al (2017) The value of advanced MRI techniques in the assessment of cervical cancer: a review. Insights Imaging 8(5):471–481
Yoshikazu O, Yumiko OT, Masato N et al (2003) MR Imaging of the uterine cervix: imaging-pathologic correlation. RadioGraphics 23:425–445
Abd elsalam SM, Mokhtar O, Lamia Adel L et al. (2020) Impact of diffusion weighted magnetic resonance imaging in diagnosis of cervical cancer. Egypt J Radiol Nucl Med 51:23
Tamai K, Koyama T, Saga T et al (2008) The utility of diffusion-weighted MR imaging for differentiating uterine sarcomas from benign leiomyomas. Eur Radiol 18(4):723–730
Patel S, Liyanage S, Sahdev A et al (2010) Imaging of endometrial and cervical cancer. Insights Imaging 1(5–6):309–328
Takeuchi M, Matsuzaki K, Harada M et al (2011) Differential diagnosis of uterine polyps: MR manifestations of various epithelial and mesenchymal tumors and tumor like lesions, pitfalls and problem-solving MR techniques. Poster No.: C-1908. Congress: ECR 2011. ESOR., EPOS. https://doi.org/10.1594/ecr2011/C-1908)
Hasan DI, Enaba MM, Abd El-Rahman HM, El-Shazely S (2015) Apparent diffusion coefficient value in evaluating types, stages and histologic grading of cancer cervix. Egypt J Radiol Nucl Med 46:781–789
Kala P, Bhargavi V, Avantsa R, Narayan G (2017) Role of diffusion weighted-magnetic resonance imaging in cervical cancer for prediction and monitoring of chemo-radiotherapy. Universal journal of medical science. Vol. 5(1):13–21
Karunya RJ, Tharani P, John S, Kumar RM, Das S (2017) Role of functional magnetic resonance imaging derived parameters as imaging biomarkers and correlation with clinicopathological features in carcinoma of uterine cervix. J Clin Diagn Res 8:XC06–XC11
Chen J, Zhang Y, Liang B et al (2010) The utility of diffusion-weighted MR imaging in cervical cancer. Eur J Radiol 74:e101–e106
Exner M, Kühn A, Stumpp P et al (2015) Value of diffusion-weighted MRI in diagnosis of uterine cervical cancer: a prospective study evaluating the benefits of DWI compared to conventional MR sequences in a 3T environment. Acta Radiologica 57(7):869–877
No available funding for this research.
Ethics approval and consent to participate
Our ethics committee guidelines are applied to all patients according to the Egyptian Network of Research Ethics Committee (ENREC).
Committee reference number: not available.
All patients had written informed consent.
Consent for publication
Every patient had written informed consent for publication of his medial data.
The authors declare that they have no competing interests.
