Duodenal angiodysplasia: a case report

Abstract

Background

Angiodysplasia (AD) is an abnormal, ectatic dilated, tortuous blood vessel that is found in the mucosa and the submucosa of the gastro-intestinal tract (GIT). While colonic angiodysplasia is a recognized finding of the lower intestinal tract in the elderly, small intestinal angiodysplasia is rare. However, it is an important reason of GIT bleeding so its detection and proper management can be a challenge. It should be considered among the differential diagnosis in the scenario of mild or intermittent GIT bleedings of obscure cause.

Case presentation

A 71-year-old woman was presented to our emergency department with hypovolemic shock due to lower GIT bleeding, and she was suffering of melena and severe anemia. The revision of past medical history revealed a history of hypertension, diabetes mellitus, and chronic renal disease. After stabilization, she underwent abdominal computed tomography (CT) which revealed a small abnormal vascular lesion along the anterior and posterior wall of the 2nd part of the duodenum. It appeared as blush of contrast in the arterial phase (representing dilated mucosal capillaries draining into tortuous submucosal vein) suggestive of vascular lesion (duodenal angiodysplasia). The patient was transferred to undergo an angiogram which confirmed the diagnosis of duodenal angiodysplasia. Super selective cannulation of the feeding artery was performed followed by post coiling angiogram which revealed successful embolization. No acute complications were encountered during or immediately after procedure.

Conclusion

AD is a rare but important cause that should be considered in the differential diagnosis of GIT bleeding especially in the older patients. It should be looked for in CT angiography done in such a clinical situation. Superselective coil embolization is a safe and effective technique to manage bowel AD.

Background

AD is an abnormal, ectatic dilated, tortuous blood vessel that is found in the mucosa and the submucosa of the GIT. It is usually sub-centimeter in its diameter. While the first case of angiodysplasia (AD) was described in the literature in 1839, that term (AD) was first defined in 1974 as abnormal mucosal vessel clusters in the colon. There was a debate regarding its true etiology that had led to having multiple synonymous terms such as angioectasia, arteriovenous malformations (AVM), and vascular ectasia [1,2,3,4].

The prevalence of angiodysplasia is increased in older populations, in patients with GI bleeding, and in patients with certain predisposing conditions such as end-stage kidney disease, von Willebrand disease, and possibly aortic stenosis. While colonic angiodysplasia is a recognized finding of the lower intestinal tract in the elderly, small intestinal angiodysplasia is rare. AD of the stomach or duodenum has been assumed as the reason of blood loss in 4 to 7% of patients with GI bleeding [5,6,7]. AD is usually detected at endoscopy being done to evaluate gastrointestinal (GI) bleeding, but in some cases, radiographic imaging or surgery may be required for detection [6,7,8,9]. So, detection and proper management of AD can be a challenge and should be considered among the differential diagnosis in the scenario of mild or intermittent GIT bleedings of obscure cause [3, 5,6,7,8,9].

Case presentation

A 71-year-old woman was presented to our emergency department with hypovolemic shock due to lower GIT bleeding. She was suffering of melena and severe anemia. The revision of past medical history revealed a history of hypertension, diabetes mellitus, and chronic renal disease. The clinical examination showed a blood pressure of 90/50 mmHg, adequate bilateral air entry, and soft abdomen. Laboratory tests showed low hemoglobin (8 g/dL) and impaired renal function. After stabilization by packed red cell transfusion, she underwent abdominal ultrasound which apart from the small kidneys was unremarkable. CT was done using Siemen (Somatom definition edge) 128 slices machine. The CT examination started by a preliminary unenhanced low-radiation dose series, then injection of intravenous contrast material through an antecubital vein with (total dose of 100 mL at rate of 4 mL/s), followed by a bolus of a 50-mL saline. The arterial phase images were done using automated bolus triggering (started when the attenuation coefficient in the proximal abdominal aorta reaches 150 HU). Portal venous phase was obtained 1-min later.

CT (Fig. 1) revealed a 1.2 × 1.5 cm abnormal small vascular lesion along the anterior and posterior wall of the 2nd part of the duodenum which appeared as blush of contrast in the arterial phase (representing dilated mucosal capillaries draining into tortuous submucosal vein) consistent with vascular lesion (duodenal angiodysplasia).

Fig. 1
figure1

a, b CT coronal reconstruction showing a small vascular lesion (yellow arrow) at 2nd part of the duodenum with a blush of contrast- and tortuous-related vessels (blue arrow) suggesting duodenal angiodysplasia

After informed consent, the patient was transferred to undergo angiogram (Fig. 2). Under complete aseptic technique and local anesthesia, a right common femoral artery access was secured by 5F sheath, through which 5F Sim II was manipulated over guide wire and placed at proximal part of the abdominal aorta (just above celiac trunk origin). Abdominal aortogram was done which showed the celiac trunk at T12. The annulation of the celiac artery followed by digital subtraction angiography (DSA) revealed celiac branches, coaxial selective cannulation of gastroduodenal artery showed abnormal arterial extravasation at the same area seen CT (suspected angiodysplasia). Super selective cannulation of feeding artery using Codman 21 microcatheter over Agility micro wire (ASAHI INTECC USA, Inc.) was done. That was followed by coil embolization using (4 pieces: 10 mm in the proximal part and others 5 mm × 30 cm Concerto Helix coils, EV3 midtronic) from distal to proximal. The aim was trapping of the lesion to prevent backflow. No other embolic agent was used. Post coiling angiogram was done reveal no more active arterial extravasation. Additionally, selective cannulation and DSA of the superior mesenteric artery (SMA) were done to be sure no retrograde filling of the lesion and to assess opened anastomosis which fills the branches of GDA branches. It revealed normal branches with no active extravasation. Femoral access sheath was removed, and hemostasis was secured by manual compression. No acute complications were encountered during or immediately after procedure. Clinically, improvement of the patient was achieved and no further complication was reported in 6 months of clinical follow-up with no further coiling or surgery.

Fig. 2
figure2

ac Celiac arteriography a angiodysplasia (yellow arrow) with early venous return (blue arrow), b selective coil embolization, and c post-embolization angiogram shows no more abnormal arterial contrast blush

Discussion

AD is one of the most recognized causes of the gastrointestinal tract hemorrhage of obscured reason. It is formed of mucosal dilated capillaries that drain into the submucosal tortuous vein. Mostly, it is less than 5 mm and can be solitary or multiple. They are more common (about 80%) to occur in the proximal part of the colon while the small bowel and upper GIT are of less incidence [1,2,3,4].

Clinical picture is variable, and the patient can be asymptomatic, having iron deficiency anemia (due to frequent bleeding) or even can be presented by acute GIT bleeding. The lesions can be undetectable at barium study and endoscopy as well as not seen at laparotomy [3, 8].

Arteriography can play an essential role in the diagnosis of angiodysplasia with high-sensitivity and low-false-negative results (< 12%) when using selective angiography technique. It can show the feeding arteriole and the related localized, berry-like vascular tufts with early filling of efferent engorged veins [3, 10, 11].

While the etiology of duodenal angiodysplasia is still not clear, some theories were postulated to explain its pathogenesis in the view of its similarity with colonic angiodysplasia. Some considered angiodysplasia to be a congenital process in patients under 20 years old with increased its incidence as the age advances which may attributed to a degenerative process. On the other hand, some considered it as an acquired lesion, attributing their assumption to the higher prevalence in old patients (> 60 years) in most studies [3, 9].

The relation of angiodysplasia to renal failure was extensively studied. It showed a higher prevalence of these lesions in renal failure patients. Some authors assumed that it can be bleeding in up to 32% of cases associated with renal failure and rebleeding in 25–47% of cases. This can be explained by several reasons such as the platelet and use of anti-coagulants in renal patient. They recommended to consider angiodysplasia as an important reason in the differential diagnosis of GIT bleeding in chronic renal failure [1, 3, 9, 12, 13].

The minimal invasiveness and availability of CT in the emergency situations together with the technical advancement of multidetector CT (MDCT) especially its high-temporal resolution made it feasible to have high-resolution multiphasic 3D datasets in short acquisition times, thus raised the usage of CT angiography in vascular lesions especially in the scenario of active hemorrhage. This can identify the bleeding source as active extravasation of the contrast material with high sensitivity and accuracy. The accuracy of CT angiography in finding the reason of GI hemorrhage can be more than 80%. Angiodysplasia is typically appear as a vascular tuft and a large draining vein [4, 14,15,16,17,18,19,20].

The management of AD is highly dependable on the clinical situation. For incidentally discovered asymptomatic non-bleeding AD, no intervention may be required as the risk of future bleeding is low. While treatment should be considered if no other source of occult or overt GIT bleeding could be identified [1].

Superselective transcatheter embolization is currently the method of choice for managing bleeding AD especially in patients with failed endoscopic therapy or unsuitable for endoscopy and also as an alternative to surgery in high-risk patients. It shows success rate of up to 90%. It usually uses biodegradable gelatin sponges and microcoils with the possibility for re-embolization for rebleeding cases [1, 21,22,23,24,25]. The complication of that procedure can include hematomas, dissection of artery, thrombus, pseudo-aneurysm, and bowel necrosis. However, the overall complications can be about 5–9% with less than 2% to be serious ones in recent techniques [1, 23,24,25,26,27,28].

In the current case, coil embolization was done through super-selective catheterization of the feeding vessel with successful outcome and no acute complication occurred.

Conclusion

AD is a rare but important cause that should be considered in the differential diagnosis of GIT bleeding especially in the older patients. It should be looked for in CT angiography done in such clinical situation. Superselective coil embolization is a safe and effective technique to manage bowel AD.
