Relationship of mammographic densities to breast cancer risk



Our goal was to find out the relation between mammographic densities and cancer of the breast according to the recent ACR classification. From the medical records of Kasereliny Hospital, 49,409 women were subjected to digital mammography for screening, of which 1500 breast cancer cases were collected. The mammographic categories of breast density were ACR-A, B, C, and D, which were detected by two senior radiologists. All radiological classifications were made using both standard mammographic views bilaterally. Two-sided tests of statistical significance were represented by all the P values.


From 2014 to 2019, 49,409 women came for digital mammographic screening, their age ranges between 40 and 65, and all of them are included in the study. One thousand cases of breast cancer cases were radiologically and pathologically diagnosed. Different densities were arranged in descending pattern depending on the frequency of positive cases: D (13.7%), C (3.3%), B (2.7%), A (2.2%). There is positive significant risk ratio among every higher mammographic density in comparison to the lower density.


Our study results show that the risk of breast cancer is in close relation to the mammographic breast density.


Screening in breast cancer is of great value in detecting asymptomatic cancer resulting in less invasive treatments and better outcome too as it will be discovered in its early stage before tumor progresses. Rules for the category of women which should be screened, how often, and by which imaging modality should be well-known [1].

Mammography is still the best recommended imaging tool for screening of breast cancer in all women which in turn depends on a common decision between the female and her clinician depending on the risk factors and competing co-morbidities [1].

Breast cancer risk is in close relation with increasing mammographic breast density. Breast in the mammogram appears as a reflection of both the amount of fat and epithelial and connective tissues together. On mammogram, fat is represented by radiolucent areas, and the non-radiolucent areas related to the glandular and fibrous tissues. Women who have increased breast cancer risk by 4–6-fold with breast density are of 75% breast density [1].

Annual mammography as well as dynamic MRI is recommended in screening high-risk breast cancer women; ultrasound is recommended only when there are contraindications to MRI. Those with intermediate risk should do annual screening mammography while dynamic MRI is recommended in some cases only. For those with average risk, annual mammography is enough [2].

The current work had presented an update analysis of the frequency of breast cancer in correlation to the type of breast density in the Egyptian female population. The study involved a large proportion of women (n=49,409) whether subjected to screening or diagnostic mammograms. To our knowledge, there was no comparable study with the inclusion of such large sample size and discussed the risk of breast cancer in Egypt.



Our study included 49,409 women outreached for screening by digital mammography. Their data were collected from the medical records of Kasereliny Hospital radiology department in the period from January 2014 to December 2019.

Inclusion criteria

Asymptomatic females above the age of 40 years who are eligible for screening mammography

Exclusion criteria

  • Mammographic contradiction, e.g., pregnant women

  • Women under 40 years, where US is the modality of choice

All patients were submitted to the following:

  • Demographic and clinical data collection

    Including patient’s age, name, phone number, marital status, number of offsprings, residence, diagnosis, duration of illness, family history, and past history

Imaging procedure

All cases did digital mammography.


  • Mammographic examination was performed using the digital mammography system (Senographe 2000 D, GE, USA).

Technique of full-field digital mammography

  • Standard views of craniocaudal and mediolateral-oblique and craniocaudal were taken for all patients.

Image analysis and interpretation of mammography

  • Mammograms were classified into four categories of density (MD), ACR-A, ACR-B, ACR-C, and ACR-D according to ACR BI-RADS atlas fifth edition 2013.

  1. a.

    The breast are almost entirely fatty.

  2. b.

    There are scattered areas of fibroglandular density.

  3. c.

    The breasts are heterogeneously dense.

  4. d.

    The breasts are extremely dense.

  • All radiological classifications were made using both standard CC and MLO views of both breasts.


This study included 49,409 women outreached for screening by digital mammography from 2014 to 2019. Their data were collected from the medical records of Kasereliny Hospital Radiology department.

The age in our study ranged between 40 and 65 years.

Among the collected cases, 11,569 were ACR-A (23%), 24,135 were ACR-B (49%), 12,250 were ACR-C (25%), and 1455 were ACR-D (3%) (Fig. 1).

Fig. 1

Percentage distribution of ACR density among all studied cases

One thousand five hundred cases of breast cancer were depicted radiologically and confirmed by histopathology.

Two hundred fifty breast cancer cases were detected in ACR-A class, 650 cases in ACR-B class, 400 cases in the ACR-C class, and 200 in the ACR-D class (Table 1).

Table 1 Breast density and increased breast cancer risk

The frequency of all the positive breast cancer cases in ACR-A density group was 2.2, ACR-B group was 2.7, 3.3 in ACR-C group, and 13.7 in ACR-D group (Fig. 2).

Fig. 2

Frequency of breast cancer as regards different mammographic densities

Densities were arranged in a descending order according to the frequency of positive cases:

D (13.7%), C (3.3%), B (2.7%), A (2.2%)

There was a significant increased risk of breast cancer with high breast densities collectively: ACR-C and ACR-D (Fig. 3).

Fig. 3

Sixty-year-old female for screening ACR C. Right UOQ irregular shape speculated outline dense lesion


There are many reasons behind the increasing rates of breast cancer in developing countries including Egypt; among these reasons is increasing breast density in women above age of 40 years [3]. So, in women over 40 years of age, breast cancer remains one of the main reasons of death [4].

Increasing breast cancer survival rate with a possibility of complete cure is mostly the result of early detection that is why annual screening mammography is a must [5].

Annual screening for breast cancer is important in detecting women with asymptomatic breast cancer and as result better outcomes [1].

Mammogram films are usually a combination of both non-radiolucent areas and radiolucent areas representing a mixture of both fibroglandular tissue and fat, so ladies with increasing percent of fibroglandular tissue of 75% or more usually show more risk of developing breast cancer by 4 to 6 folds in comparison to those with increasing fatty component in mammogram [6].

Some of the studies used Wolfe classification instead of BI-RADS density classification in explaining the relation between the risk for breast density and breast cancer risk. Use of the BI-RADS classification has resulted in a similar but milder relation of risk with respect to breast density [7]. One study of the Vermont population from the BCSC registry that implied the BI-RADS density classifications stated that extremely dense breasts in women have increased breast cancer relative risk ratio in premenopausal than in post-menopausal females [8].

Ahmadinjad et al. showed that the occurrence of malignancy in dense breast patients (61.2%) is more than in those with low breast densities (37.3%) (P= 0.007) as stated in our study that the frequency of breast cancer in groups ACR C and ACR D is more than the frequency rate in groups ACR A and ACR B [9].

According to the BI-RADS edition 2013, cases were classified into the following: 11,569 were ACR-A (23%), 24,135 were ACR-B (49%), 12,250 were ACR-C (25%), and 1455 were ACR-D (3%).

Our study included 49,409 women, 1500 cases were pathologically proven with breast cancer out of the total. Out of the 1500 breast cancer cases, 250 were depicted in ACR-A class and 650 in ACR-B class, 400 cases in the ACR-C class, and 200 in the ACR-D class.

Cases were ordered in a descending pattern depending on the frequency of carcinoma positive cases:

D (13.7%), C (3.3%), B (2.7%), A (2.2%)

The positive relationship between increasing the risk of breast cancer in women with increasing breast mammographic density has been reported in many cohort studies [10]. Byrne et al. stated that women with breast density of 75% or more showed four-fold increase in the risk affection with breast cancer than those with mammographic density of 0% [11].

As stated in our study, Maskarinec et al. also discovered that the risk for breast cancer affection increases by 3.6 times in women with breast density more than 50% than women with density less than 10% [12].

Some studies reported that the relative cancer risk for breasts that were 50–74% dense was 2.92 and 4.64 for breasts that were 75% or more dense; as a result, there is a linear increasing trend between the relation of the breast cancer relative risk and increasing tissue breast density which was also reported in our study [7].

In our study, we found that women with ACR mammographic density class D and C have statistically increase frequency of positive carcinoma patients than class A and B.


We finally concluded that there is a significant positive relation between increase in the risk of breast cancer in our population with increasing mammographic breast tissue density.

Availability of data and materials

The data sets used and/or analyzed during the current study are available from the corresponding author on reasonable request.



American College of Radiology


Magnetic resonance imaging


Breast imaging-reporting and data system


Mammographic density


  1. 1.

    Mackenzie SF, Christoph IL, Joann GE (2015) Breast cancer screening an evidence-based update. Med Clin N Am 99(3):451–468

    Article  Google Scholar

  2. 2.

    Martha BM, Ana L, Mary CM, Mary SN, Lisa B, Lora DB, D’Orsi C, Jennifer AH, Mary KH, Huynh PT, Peter MJ, Lee S-J, Constance DL, David AM, Joshua AN, Samir BP, Handel ER, Linda S, Bruce GH (2012) ACR Appropriateness Criteria Breast Cancer Screening

    Google Scholar

  3. 3.

    Jamal A, Center MM, DeSantis C and Ward EM (2010). Global patterns of cancer incidence and mortality rates and trends. Cancer Epidemiol Biomark Prev 19(8):1893-1907

  4. 4.

    Yang T, Liang H, Chouc C, Huang J, Pan H (2013) Adjunctive digital breast tomosynthesis in diagnosis of breast cancer. Biomed Res Int 597253.

  5. 5.

    KöşüşN KA, Duran M, Simavlı S, Turhan N (2010) Comparison of standard mammography with digital mammography and digital infrared thermal imaging for breast cancer screening. Assoc. J Turk Ger Gynecol Assoc 11(3):152–157

    Article  Google Scholar

  6. 6.

    Tamimi RM, Byrne C, Colditz GA, Hankinson SE (2007) Endogenous hormone levels, mammographic density, and subsequent risk of breast cancer in postmenopausal women. J Natl Cancer Inst. 99(15):1178–1187.

    CAS  Article  PubMed  Google Scholar

  7. 7.

    McCormack VA, dos Santos SI (2006) Breast density and parenchymal patterns as markers of breast cancer risk: a meta-analysis. Cancer Epidemiol Biomarkers Prev 15(6):1159–1169.

    Article  PubMed  Google Scholar

  8. 8.

    Vacek PM, Geller BM (2004) A prospective study of breast cancer risk using routine mammographic breast density measurements. Cancer Epidemiol Biomarkers Prev 13(5):715–722

    PubMed  Google Scholar

  9. 9.

    Ahmadinjad N, Movahedinia N, Shahriari M (2013) Iranian Red Crescent Med J 15(12):e16698

    Google Scholar

  10. 10.

    Boyd NF, Go H, Martin LJ, Sun L, Stone J, Fishell E et al (2007) Mammographic density and the risk and detection of breast cancer. N Engl J Med 356(3):227–236.

    CAS  Article  PubMed  Google Scholar

  11. 11.

    Byrne C, Schairer C, Wolfe J, Parekh N, Salane M, Brinton LA, Hoover R, Haile R (1995) Mammographic features and breast cancer risk: effects with time, age, and menopause status. J Natl Cancer Inst 87(21):1622–1629.

    CAS  Article  PubMed  Google Scholar

  12. 12.

    Maskarinec G, Pagano I, Lurie G, Wilkens LR, Kolonel LN (2005) Mammoraphic density and breast cancer risk. Am J Epidemol 162(8):743–752.

    Article  Google Scholar
