COVID-19 neurological manifestations: correlation of cerebral MRI imaging and lung imaging—Observational study

Abstract

Background

During the current pandemic, there is an increased incidence of neurologic/neuropsychiatric manifestations in patients with the novel coronavirus (COVID-19). Neurologic manifestations may be coincident or result of disease and its therapy. In the emergency department, orientation of the clinician with this issue is crucial for accurate decision making to limit the spread of infection during neurologic treatment. This study aimed to be familiar with MRI findings in patients with Neuro-COVID. Seventy patients presented with neurologic/neuropsychiatric manifestation either post COVID or during hospitalization underwent cerebral MRI from April 2020 to June 2021 (39 men and 31women; mean age 43.27, age range from 16 to 69 years).

Results

Headache (80%), is the most prevalent neurological manifestations followed by smell and taste impairment (62.9%) and stroke symptoms (45.7%). Low mood and anxiety (17.1%), prolonged fatigue (14.3%) and depression (7.1%) are the most common psychiatric symptoms. Infarctions, hematoma and demyelinating disease are the most prevalent findings. There is a week positive correlation between MRI findings and CT chest finding but without statistical significance (P-value 0.2).

Conclusions

Cerebrovascular disease and demyelinating lesions are common manifestations of COVID 19. Familiarity of neurologists and radiologist in the emergency department and in-patient with this issue is crucial to avoid misdiagnosis and the spread of infection.

Background

The coronaviruses (CoVs) are a large group of positive-strand RNA viruses characterized by club-like spikes that project from their surface, an unusually large RNA genome, and a unique replication strategy. CoVs cause various diseases range from mild respiratory disease, enteritis and potentially lethal respiratory infections [1].

In March 2020, the World Health Organization (WHO) declares 2019 novel coronavirus (COVID 19) that was first identified in Wuhan, China in December 2019 as a global pandemic. By June 2021, There have been 175,541,600 confirmed cases of COVID-19, including 3,798,361 deaths, reported to WHO [2].

COVID-19 is highly contagious disease. Although the respiratory system remains the most primarily affected organ, a wide-ranging multi-organ disease has evolved. Several case reports revealed that the neurotropic and neuroinvasive properties of the virus leading to neurological diseases [3].

Neurological symptoms in COVID-19 patients may arise due to (1) Viremia with subsequent injury to vascular endothelial and epithelial cells (disruption of BBB), (2) hypoxic injury due to respiratory failure and prolonged ventilation that facilitated entry of the virus into neural tissue cells, (3) retrograde -upper nasal trans-cribrial neuronal route and direct damage to the olfactory and gustatory receptors (neurotropism of CoVs enables the COVID-19 to reach the brain), (4) immune injury secondary to cytokine storm syndrome and heighten state of inflammation, (5) COVID-19 induced coagulopathy, (6) COVID-19 bind and engage with the ACE2 receptors, COVID-19 docks on the ACE2 via spike protein (lungs, heart, kidneys, intestines, brain, and testicles are well-known to express ACE2 receptors) and are possible targets of COVID-19 [4].

Aim: To be familiar with MRI findings in patients with Neuro-COVID.

Methods

Patients

A single-center prospective observational study was conducted at a tertiary care center in a University Hospital. Seventy patients with past or present history of typical COVID-19 infection who presented with neurologic/ neuropsychiatric symptoms (with or without respiratory symptoms) between April 2020 and June 2021. Demographic data (age, sex), medical history of comorbid diseases (diabetes mellitus, hypertension, chronic kidney disease, cardiac disease, cancer, SLE, RA), complete clinical and neurological examination and laboratory findings were done.

Patients with previous neurocognitive disorders were excluded from the study. An ethical approval was obtained from local ethics committee.

Neuro-COVID manifestations were categorized into two classes: I. neurologic manifestations including headache, impaired consciousness, and acute cerebrovascular disease, extrapyramidal manifestation, anosmia, ageusia, II. psychiatric symptoms including low mood and anxiety, depression, prolonged fatigue and insomnia.

Method

  • MRI using a 1.5 T MR scanner (Signa;16 channel, Excite, GE Healthcare, Milwaukee, WI, USA). MR sequences parameters were as follows: T1-weighted images parameters: (TR:360 ms, TE: 9 ms), T2-weighted images parameters (TR:6672 ms, TE: 147 ms), GRE T2* (TR: 46.5, TE: 2.5, flip angle: 10°). FLAIR (TR: 7432, TE: 118.6, inversion time (TI):2200). Diffusion weighted images with B value 1000. Examination with a head coil. Field of view (FOV) 22 × 18 mm; matrix, 310 × 620; slice thickness, 3 mm and slice gap, 0.4 mm. MRV (TR: 20.1, TE: 5.2, Flip angle: 32, Matrix 235, FOV:200).

  • CT chest at time of admission for patient in acute phase and new CT chest for patient with post-COVID new symptoms to rule out possibility of re-infection.

  • Image interpretation and analysis:

Two radiologists interpreted the images in conjunction. One reader (E.S) had 14 years of experience interpreting, and the second reader (R.S) had 15 years of experience.

Statistics

Data were described as number, mean ± standard deviation (SD) and frequency (percent) for categorical data. The distribution of categorical data was assessed using chi square test (with exact p-value). P < 0.05 was considered as significance level. Correlation of finding were tested using Pearson and Spearmen test. All statistical analyses were analysed using IBM SPSS software package version 25.0 (Armonk, NY: I BM Corp).

Results

Seventy patients presented neurologic/ neuropsychiatric symptoms with typical COVID-19 infection; age ranged from 16 to 69 years with the mean age of 43.27 ± 13.99 years were enrolled. (55.7% male, 44.3 female). Post-COVID-19 neuro-COVID was detected in 62 out of 70 patient (88.6%), while 8 out of 70 patient (11.4%) developed neurological symptoms during admission with typical COVID. The most prevalent neurological manifestations in the studied participants. Headache (80%), and smell and taste impairment (62.9%), followed by stroke symptoms (45.7%) were the most prevalent neurologic symptoms. Low mood and anxiety (17.1%) were the most common psychiatric symptoms, followed by prolonged fatigue (14.3%). Depression was the least common neuropsychiatric symptoms represented (7.1%) (Table 1).

Table 1 The frequency of neurological manifestations in patients with COVID-19

The majority (62.9%) had comorbidities. The most common comorbidity was HTN and diabetes (Table 2).

Table 2 The frequency of comorbidity and neurological manifestations in patients with COVID-19

Lung imaging, revealed that CO-RAD IV and V (75.7%), were the most common CT findings followed by CO-RAD III (20%) (Table 3).

Table 3 The frequency of chest findings in examined patients

The most common MRI finding were cerebrovascular stroke: infarction 37.14% (Figs. 1, 2 and 3), hematoma 20% (Fig. 4), vasculitis 15.7% (Fig. 5), demyelinating disease 14.28% (ADEM 7.1%, PRES 7.1%), gyral edema 5.7% (Fig. 6) and common WM micro haemorrhage 2%) (Table 4).

Fig. 1
figure 1

A 36-year-old male patient, presented with post-COVID headache, seizers and disturbed consciousness. a MRI axial T2WI revealed cortical and subcortical regions of high T2-signal intensities represents non haemorrhagic venous infarctions. b Corresponding regions of restricted diffusion in DWI with b-value1000. c, d and e MRV show near complete obstruction of the superior sagittal sinus. Non haemorrhagic venous infarction is confirmed. f CT chest showed peripheral distributed ground glass opacities typical for COVID-19 (CORAD-V)

Fig. 2
figure 2

A 43-year-old female patient presented with post COVID fatigue, followed by cerebrovascular stroke symptoms. MRI axial T1WI (a) revealed left occipital subcortical white matter abnormal signal display relative low signal intensity (arrow). Axial T2WI (b) show high SI with no mass effect. Axial FLAIR (c) showed corresponding increase signal intensity. DWI (d, e) showed areas of restricted diffusion. watershed infarcts with additional foci of lacunar infarcts. CT lung showed GGO very typical for COVID (CORAD-V)

Fig. 3
figure 3

A 50-year-old male patient presented with cerebrovascular stroke post COVID. MRI a axial T1WI, b axial T2WI, c axial FLAIR revealed no abnormality. d ADC map, e DWI revealed a well-defined area of restricted left parietal region acute infarction. f CT chest at admission showing CORAD III (mosaic CT attenuation). CT chest during acute phase is not available

Fig. 4
figure 4

A 50-year-old male presented with sever continuous headache during COVID infection, expressive aphasia. MRI revealed right occipital well defined intra axial space occupying lesion. a Axial T1 WI showed area of peripheral high SI with central area of iso intense signal intensity. b Axial FLAIR show area of peripheral edema (c) axial T2WI showed area of relative low SI with peripheral edema (d) ADC map and (e) DWI show area of peripheral restriction. Finding correlates with subacute intraparenchymal hematoma. f CT lung showed multifocal GGO and consolidation, very typical COVID abnormalities (CORAD-V)

Fig. 5
figure 5

A 17-year-old female patient with chronic kidney disease presented with post COVID puerperal skin rash, headache and decreased conscious level. MRI axial T2WI (a) hardly detect abnormal signal and axial FLAIR (b) revealed abnormal foci of increased signal intensity in right periventricular deep white matter (blue arrows). Diffusion images (c) show no restricted diffusion. Post COVID vasculitis was considered. CT chest during acute phase not shown. CT chest at time of admission show no abnormalities (CORAD-I)

Fig. 6
figure 6

A 47-year-old male patient presented with post COVID ophthalmoplegia in six cardinal directions, MRI a axial T1WI, b axial T2& c axial FLAIR d DWI show left occipital gyral edema with no diffusion restriction. In addition to ethmoidal sinusitis which show restricted diffusion in DWI (e) and of high FLAIR SI (f), histopathologically proved to be invasive fungal sinusitis. CT chest showed pulmonary nodule (short black arrow) probably post COVID infection sequel CORAD-III

Table 4 The MRI findings of neurological manifestations in patients with COVID-19

MRI successfully detected serious COVID complication namely invasive fungal sinusitis (Fig. 6). On the other hand, MRI failed to detect abnormality in 2 cases that revealed normal MRI in spite that one patient was complaining of severe headache and the other patient had prolonged fatigue.

The correlation between neuro-COVID and respiratory COVID MRI was very week; Pearson's R correlation coefficient was approximately + 0.19, Spearman's correlation coefficient, rs, was 0.276, and those were was statistically insignificant (p = 0.2) (Table 5).

Table 5 Correlation between MRI findings and lung imaging

Discussion

The COVID-19 outbreak has been the subject of considerable attention all over the world due to its high contagious properties. It primarily targets the respiratory epithelium but also has neuro-invasive potential. Indeed, neuropsychiatric manifestations, such as fatigue, headache, psychiatric symptoms, and delirium, are consistently observed in COVID-19. Neuro-COVID-19 is increasingly becoming an accepted term among scientists and clinicians. The neurobiological basis of viral infections pointed to an ongoing neuroinflammatory response to viral antigens and proinflammatory mediators/immune cells [5].

Interdisciplinary teams should be created to implement strategies for treating the wide range of neurological symptoms in Neuro-COVID-19 patients [4].

The prevalent neurological symptoms among individuals with COVID-19 disease should not be under-estimated during the current pandemic outbreak [6].

This study findings demonstrate that MRI imaging in neuro-COVID-19 has a high clinical impact. And pick up the prevalent and frequent neurological symptoms were the headache (80%), anosmia or olfactory dysfunction (62.9%) was the most frequent symptom. Other symptoms of great significance were stroke like manifestation (motor/ sensory impairment and transient ischemic attack in the form of temporary loss of vision), extrapyramidal manifestation (1.4%) was one of the least frequent symptoms. On the other side; anxiety and low mood (17.1%) is the most frequent psychiatric symptom followed by fatigue (14.3%). Depression (7.1%) is the least psychiatric symptom. These results were in concordance to cross-sectional study done by Carcamo Garcia et al. [7] who found that the most common neurological symptoms were headache (72%), hypogeusia or ageusia (41%), hyposmia or anosmia (40%). While they were in discordant to Study conducted by Soltani et al. [8] which indicated that, the prevalence of CNS or mental associated disorders was 50.68%. The most prevalent symptoms were hyposmia/ anosmia/ olfactory dysfunction, while the prevalence of depression and anxiety was 3.52%. Also study done by Ortelli et al. [9] stated that more than half of patients who recover from COVID-19 experience fatigue. The study conducted by Chuang et al. [10] revealed that impaired consciousness was the most common initial neurologic symptom, followed by stroke, unsteady gait, headache, seizure, syncopal event, acute vision changes, and intracranial hemorrhage.

On the opposite side, Goel et al. [11] proved that the most commonly reported COVID neurological complications are cerebrovascular accidents, encephalopathy, encephalitis, meningitis, and Guillain-Barr e syndrome (GBS).

The comorbidity is potentially complicating the course of COVID-19; 62.9% of patients had associated comorbidities, the most common is HTN in 20 (28.6%) patients, DM were 12 patient (17.1%), morbid obesity 8 (11.4%) patient, cardiac disease 6 (8.6%) patients, and lymphoma were 2 (2.9%) patients. Multiple patients had multiple comorbidities especially in SLE and CKD. These results were in agreement to studies done by Khedr et al. [12] and Gusev et al. [13] who stated that hypertension, diabetes mellitus, ischemic heart disease and rheumatic disorders were the most common comorbidities in patients with CNS affection. In contrast to study of Carcamo Garcia et al. [7] who found that majority (42%) had no prior comorbidities.

In the present study, most patients with Neuro-COVID-19 survived (n = 47); a considerable number of patients died (n = 12); and the rest had unclear outcomes (n = 11). This was in agreement to study of Collantes et al. [14] who demonstrated that most patients with Neuro-SARS survived.

In the present study, no statistical significance between severity of Neuro-COVID and respiratory COVID. In contrary to Gusev et al. [13] who found a relationship between the severity of COVID-19 and the severity and frequency of neurological manifestations. Severe neurological disorders are mostly seen in severe cases of COVID-19 and include acute cerebrovascular accidents (aCVA), acute necrotizing encephalopathy, and Guillain–Barre syndrome. The difference may be a result of different methodology as Gusev et al. [13] studies the hospitalized patients and did not include outpatient clinic cases.

The most common MRI findings were infarctions (acute, subacute, large or lacunar) followed by hematoma. Haemorrhage may be microbleeds in the white matter. Abnormalities in the white matter may results from ADEM or PRES. Post ictal edema can be depicted easily. In 2.8%, false negative imaging, MRI failed to pick up any abnormality to explain neurologic deficit. This was in agreement to studies done by Revzin et al. [15] and Ellul et al. [16] who described variety of cerebro-vascular stroke in neuro-COVID and opposite to Poyiadji et al. [17] who described acute necrotizing encephalopathy as post COVID complication.

Due to the urgency of the COVID-19 pandemic, this study had some limitations. First, it was a single institutional study. Second, as Neuro-COVID patients had varying degrees of disease severity, from light headache to critically ill patients and MRI was performed commonly in severely ill patients, patient selection bias is possible. Third, the lack of a control group limits our findings to Neuro-COVID-19. Forth, the lack of histopathologic data is also a limitation. Finally, the limited availability of long-term clinical outcomes.

These limitations necessitate international longitudinal studies for a more detailed analysis of co-morbidities and to determine the long-term neurological sequelae of COVID-19 during the acute and post-infectious period [18].

Conclusion

During the current pandemic, neurologists should be aware of the possibility of Neuro-COVID 19 infection in patients with neurological damage in the emergency department to avoid misdiagnosis or the spread of infection. Hospitalized patients with COVID-19 infection may show symptoms of neurological damage, such as cerebrovascular disease, and demyelinating lesions. However, no statistical significance between neuroimaging and lung imaging in COVID-19 patients.

Availability of data and materials

The datasets used and/or analysed during the current study are available from the corresponding author on reasonable request.

Abbreviations

CoVs:

Coronaviruses

COVID 19:

Novel coronavirus

WHO:

World Health Organization

SD:

Standard deviation

HTN:

Hypertension

DM:

Diabetes mellites

SLE:

Systemic lupus erythematosus

CKD:

Chronic kidney disease

PRES:

Posterior reversible encephalopathy

ADEM:

Acute disseminated encephalomyelitis

References

  1. Fehr AR, Perlman S (2020) Coronaviruses: an overview of their replication and pathogenesis. Methods Mol Biol 1282:1–23

    Google Scholar

  2. WHO Coronavirus (COVID-19) Dashboard: WHO Health Emergency Dashboard (2021) [cited 2021 14.06.2021]. Available from: https://COVID19.who.int/.

  3. Aslan C, Nikfarjam S, Asadzadeh M, Jafari R (2021) Neurological manifestations of COVID-19: with emphasis on Iranian patients. J Neurovirol 27(2):217–227

    CAS  Article  Google Scholar

  4. Davies DA, Adlimoghaddam A, Albensi BC (2021) The effect of COVID-19 on NF-kappaB and neurological manifestations of disease. Mol Neurobiol. 58:4178–4187

    CAS  Article  Google Scholar

  5. Chaves Filho AJM, Goncalves F, Mottin M, Andrade CH, Fonseca SNS, Macedo DS (2021) Repurposing of Tetracyclines for COVID-19 neurological and neuropsychiatric manifestations: a valid option to control SARS-CoV-2-associated neuroinflammation? J Neuroimmune Pharmacol 16(2):213–218

    Article  Google Scholar

  6. Amanat M, Rezaei N, Roozbeh M et al (2021) Neurological manifestations as the predictors of severity and mortality in hospitalized individuals with COVID-19: a multicenter prospective clinical study. BMC Neurol 21(1):116

    CAS  Article  Google Scholar

  7. Carcamo Garcia MH, Garcia Choza DD, Salazar Linares BJ, Diaz MM (2021) Neurological manifestations of patients with mild-to-moderate COVID-19 attending a public hospital in Lima. Peru. eNeurologicalSci 23:100338

    Article  Google Scholar

  8. Soltani S, Tabibzadeh A, Zakeri A et al (2021) COVID-19 associated central nervous system manifestations, mental and neurological symptoms: a systematic review and meta-analysis. Rev Neurosci 32(3):351–361

    CAS  Article  Google Scholar

  9. Ortelli P, Ferrazzoli D, Sebastianelli L et al (2021) Neuropsychological and neurophysiological correlates of fatigue in post-acute patients with neurological manifestations of COVID-19: insights into a challenging symptom. J Neurol Sci 420:117271

    CAS  Article  Google Scholar

  10. Chuang DT, Aydemir S, Magda P, Thomas C, Zarnegar R (2021) Neurological manifestations as primary presentation of COVID-19 in hospitalized patients. Acta Neurol Scand 143(5):569–574

    CAS  Article  Google Scholar

  11. Goel K, Kumar A, Diwan S et al (2021) Neurological manifestations of COVID-19: a series of seven cases. Indian J Crit Care Med 25(2):219–223

    CAS  Article  Google Scholar

  12. Khedr EM, Abo-Elfetoh N, Deaf E et al (2021) Surveillance study of acute neurological manifestations among 439 Egyptian patients with COVID-19 in Assiut and Aswan University Hospitals. Neuroepidemiology 55(2):109–118

    Article  Google Scholar

  13. Gusev EI, Martynov MY, Boyko AN et al. The novel coronavirus infection (COVID-19) and nervous system involvement: mechanisms of neurological disorders, clinical manifestations, and the organization of neurological care. Neurosci Behav Physiol. 2021;1–8.

  14. Collantes MEV, Espiritu AI, Sy MCC, Anlacan VMM, Jamora RDG (2021) Neurological manifestations in COVID-19 infection: A systematic review and meta-analysis. Can J Neurol Sci 48(1):66–76

    Article  Google Scholar

  15. Revzin MV, Raza S, Srivastava NC et al (2020) Multisystem imaging manifestations of COVID-19, part 2: from cardiac complications to pediatric manifestations. Radiographics 40(7):1866–1892

    Article  Google Scholar

  16. Ellul M, Varatharaj A, Nicholson TR et al (2020) Defining causality in COVID-19 and neurological disorders. J Neurol Neurosurg Psychiatry 91(8):811–812

    Article  Google Scholar

  17. Poyiadji N, Shahin G, Noujaim D, Stone M, Patel S, Griffith B (2020) COVID-19-associated acute hemorrhagic necrotizing encephalopathy: imaging features. Radiology 296(2):E119–E120

    Article  Google Scholar

  18. Zhao F, Han Z, Wang R, Luo Y (2021) Neurological manifestations of COVID-19: causality or coincidence? Aging Dis 12(1):27–35

    Article  Google Scholar
