The F-18 FDG PET/CT evaluation of the metastatic adrenal lesions of the non-lung cancer tumors compared with pathology results

Egyptian Journal of Radiology and Nuclear Medicine volume 53, Article number: 16 (2022) Cite this article

Abstract

Background

The aim of this study was to evaluate the role of F-18 FDG PET/CT imaging in the diagnosis of primary and metastatic adrenal tumors that originate from non-lung cancer primary tumors.

Results

F-18 FDG PET/CT images of patients (8 male and 6 female; mean: 55.36 ± 16.2 years old) who attended with the diagnosis of primary or adrenal metastatic lesions other than lung cancer metastasis were evaluated in a retrospective manner. The diameter of the adrenal lesions was mean: 23.93 ± 36.6 mm with SUVmax levels of mean: 9.98 ± 7.8. The primary site of 2/3 of the patients with unknown primary was the adrenal gland, and in one of the patients primary tumor remained unknown during follow-up.

Conclusions

According to the results of this study, F-18 FDG PET/CT has high diagnostic performance in the diagnosis of the adrenal gland primary and metastatic lesions, which originate from non-lung cancer tumors. Further studies in the larger series are warranted.

Introduction

The most common tumor that metastasizes to the adrenal gland is lung carcinoma; however, gastrointestinal tumors may also metastasize to the adrenal gland. Metastatic and primary tumors of the adrenal gland have significant fluorodeoxyglucose (FDG) uptake, and thus, these tumors might be visualized by F-18 FDG positron emission tomography (PET)/computerized tomography (CT). There are several reports about the diagnostic performance of F-18 FDG PET/CT in the discrimination of malignant and benign adrenal lesions [1]. Additionally, the diagnostic utility of F-18 FDG PET/CT in metastatic adrenal lesions has been addressed by multiple studies previously in the literature [2]. There are also case reports about the impact of F-18 FDG PET/CT in the patients’ management in the patients with metastatic adrenal lesions [3,4,5]. Metabolic characterization of primary adrenal tumors might be performed by F-18 FDG PET/CT as well [6, 7]. However, there are no previous studies regarding this specific group of metastatic tumors that originate from primary sites other than lung carcinoma in the literature. The diagnostic performance of F-18 FDG PET/CT in the evaluation of primary and metastatic adrenal gland lesions was the aim of this study.

Methods

Patients

Fourteen patients (8 male and 6 female; mean: 55.36 ± 16.2-year-old Caucasian patients) who had metastatic or primary tumors of the adrenal gland and had non-lung cancer with primary tumor or without primary tumor were included in the study. The diagnosis of known malignancy was recorded in 11 patients and unknown primary tumor in three patients. The lactation, pediatric age and gestatation were the exclusion criteria for the study, and inclusion criteria were referral of the patients with diagnosis of a known malignancy other than lung cancer and documented metastatic lesion on adrenal gland (SUVmax levels two times more than the physiological liver uptake and or mass–mass-like lesion on surrenal gland suggesting metastasis). The patients with known primary tumors were referred to the Nuclear Medicine Department for staging (n = 2) and treatment response evaluation (n = 9). The study was approved by the ethics committee, and the informed consents of the patients were obtained for the imaging examination.

Imaging

The F-18 FDG PET/CT examination was performed after fasting for at least 6 h. The F-18 FDG was injected (approximately mean 370 MBq-10 mCi/at the dose adjusted according to the body weight) to the patients intravenously 60 min before the imaging. F-18 FDG PET imaging was performed by the PET/CT camera (GE, Discovery PET/CT 610, US) with a low-dose CT scan (130 kV, 50 mAs, a pitch of 1.5, a thickness of 5 mm, in 70 cm field of view) for attenuation correction in craniocaudal direction for 1 min per bed position.

Analysis

The F-18 FDG PET/CT images of the patients with metastatic or primary adrenal lesions were evaluated retrospectively by an experienced Nuclear Medicine physician and the dimensions and uptake values (SUVmax) of the lesion, characteristics of the patients as well as primary site and other metastatic sites were recorded. The F-18 FDG PET/CT imaging results were compared with the pathology, follow up or Magnetic resonance imaging (MRI) results as the gold standard.

Results

Fourteen patients (8 M/6 F; mean: 55.36 ± 16.2 years old) with the diagnosis of adrenal lesions were included in the study. The patients included in this study did not have the diagnosis of lung cancer. Among the patients who were referred for primary tumor investigation; the primary site of 2/3 patients was the adrenal gland and 1 patient remained unknown. The primary tumors of the patients were the gastrointestinal tract (stomach n = 1 and colon n = 6) and other tumors (Table 1).

Table 1 The summary of the findings of patients included in the study
Full size table

The adrenal gland lesions of the patients were at right side (n = 6) and left side (n = 6) and bilateral (n = 2) according to the frequency. The dimension of the adrenal gland lesions was mean: 23.93 ± 36.6 mm, and the SUVmax level of the adrenal lesions was mean: 9.98 ± 7.8.

The F-18 FDG PET/CT results revealed other metastatic lesions with distribution of the other metastatic lesions were mediastinum (n = 7), lung (n = 5), liver (n = 7), abdominal lymph node (n = 4), bone (n = 3), mesenteric lesions (n = 5) and cervical lymph nodes (n = 4).

The pathology/follow-up MRI results demonstrated metastatic (n = 13) and primary (n = 2) tumors of the adrenal gland as listed in table. One of the patients with primary sarcomatoid carcinoma (Fig. 1a–e) of the adrenal gland died during the disease course. In the follow-up a total of 8/14 patients died.

Fig. 1
figure 1

a The multiple intensity projection image of the patient diagnosed as primary adrenal tumor showing right adrenal enlarged mass, abdominal metastatic lymph nodes and lung metastases. b The follow-up F-18 FDG PET/CT MIP image of the same patient two sickles after the chemotherapy showing shrinkage of the primary tumor, and no lymph node metastasis but also new developing lung metastasis and bone marrow uptake were also observed. c Cohesive tumor cell clusters with focal necrosis, HE, 40 ×. d Tumor cells with nuclear atypia and necrosis, HE, 200 ×.Table 1: The characteristics and results findings of the patients included in the study

Full size image

Discussion

In a previous series including patients with the diagnosis of the hepatocellular carcinoma, it was concluded that F-18 FDG PET/CT has limitations in the differential diagnosis of benign and malignant metastatic lesions [8] probably because primary and metastatic lesions of the hepatocellular carcinoma demonstrate variable FDG uptake. In this specific group of patients with HCC, it has been suggested to image with dual tracer modality C-11 choline and F-18 FDG in a previous study [9]. This study was the only study which evaluated the metastatic lesions of adrenal gland in this specific group of patients. According to the results of this study, F-18 FDG PET/CT clearly demonstrates the metastatic and primary adrenal lesions in the patients other than lung carcinoma. However, there are several other example cases of lack of FDG accumulation in adrenal lesions with specific other pathology types [10].

According to a previous study, F-18 FDG PET/CT has higher diagnostic accuracy compared to the contrast-enhanced CT in the determination of primary adrenal tumors and SUVmax has prognostic value [6]. The patients in this study group with higher SUVmax values died during the follow-up, but we did not analyze the prognostic value of this parameter due to small sample size. This issue might be evaluated in another study in a larger patient population. The F-18 FDG PET/CT provides additional information in the patients with recurrent or metastatic primary adrenal masses according to the literature [11]. In this series, the metastatic lesions of primary adrenal tumors were clearly indicated and treatment response evaluation of a case was performed efficiently by F-18 FDG PET/CT as well. In a previous study about primary adrenal carcinoma, F-18 FDG PET/CT have influenced the patients’ management by correct determination of the primary tumor and provided staging at a single study [12, 13]. In the patients presented in this study, the PET/CT imaging changed the patients’ management by correctly identifying the primary tumor in two of three patients with unknown primary tumor (60%) and correctly staged the patients (Fig. 2).

Fig. 2
figure 2

Sixty-nine-year-old female patient with the diagnosis of metastatic colon carcinoma; the coronal fusion FDG PET/CT slices corresponding to multiple metastatic adrenal lesions with significant FDG accumulation with the greatest dimension of 23 mm (SUVmax = 6.9 right/SUVmax = 8.3 left-liver background SUVmax = 3.9)

Full size image

According to the study by Launay et al., the SUVmax value and the adrenal-to-liver SUVmax ratio might help to determine the malignancy in the patients with indeterminate adrenal lesions [14]. They have demonstrated primary (32/67), metastatic lesions (n = 19) and adenoma (n = 16) in their series which were verified by the pathology results [14]. Another study indicated a SUVmax cutoff level for discrimination of benign and malignant adrenal lesions [15]. The diagnostic performance of the F-18 FDG PET/CT in the characterization of primary and metastatic adrenal lesions as well as extra-adrenal lesions (unknown primary and staging) was sufficient in this present study.

Metastatic lesions of the adrenal gland are also candidates for surgical management, and there are case reports with good outcome after adrenalectomy as a single site of metastasis determined by F-18 FDG PET/CT [16, 17]. The metastatic lesions of adrenal gland have been determined to be higher in autopsy series compared to the clinical studies [18]. The ratio of adrenal metastasis of the primary esophagus tumor has been observed to be 10% in a previous case series [19]. The results of this study also indicated a significant influence of the F-18 FDG PET/CT in the management of the patients with primary or metastatic adrenal lesions. Overall and disease-free survival of the patients with adrenalectomy due to metastatic lesion was good according to the previous reports [5, 20,21,22]. However, there were a significant number of the patients who died during follow-up in this series, but we did not analyze the mortality of the patients due to small sample size. This issue might be evaluated by future studies in larger series.

A review including 29 studies has pointed that the F-18 FDG PET/CT has high diagnostic accuracy in the determination of adrenal masses [23]. A previous study has indicated that adrenal metastasis could not be differentiated by means of contrast enhanced CT due to significantly low sensitivity [24]. Another review concluded that the diagnostic utility of the F-18 FDG PET/CT is significantly better with additional semi quantitative analysis compared to CT and MR in the determination of the adrenal masses [25]. Another recent study indicated the diagnostic significance of the F-18 FDG PET/CT in the discrimination of malignant versus benign adrenal tumors [26]. There are also case reports of the rarer pathologies metastatic to the adrenal gland [27, 28].

The limitation of this study was the lack of follow-up results of all the included patients due to the retrospective structure of the study and limited number of patients.

Conclusion

This study verified the sufficient diagnostic power of the F-18 FDG PET/CT in the determination of the primary and metastatic tumors of the adrenal gland. All the lesions included in this study showed significant FDG uptake. This is the first report about determination of metastatic lesions other than lung metastasis and primary lesions of the adrenal gland by FDG PET/CT as far as we know in the literature.

Future perspective

Probably, the F-18 FDG PET/CT might be the modality of choice in the determination of the primary or the metastatic adrenal tumors. As an accurate staging modality, the F-18 FDG PET/CT would be a part of evaluating metastatic adrenal tumors in both patients with lung cancer and non-lung cancer. Further studies are required in larger populations in order to determine the prognostic value and impact of the patient management of the FDG PET/CT.

Availability of data and materials

Not applicable

Abbreviations

F-18 FDG PET/CT:

F-18 Fluorodeoxyglucose Positron Emission Tomography/Computed Tomography

References

  1. Kim JY, Kim SH, Lee HJ, Kim MJ, Kim YH, Cho SH (2013) Utilisation of combined 18F FDG PET/CT scan for differential diagnosis between benign and malignant adrenal enlargement. Br J Radiol 86:20130190

    Article  CAS  Google Scholar

  2. Kumar R, Xiu Y, Yu JQ et al (2004) 18F-FDG PET in evaluation of adrenal lesions in patients with lung cancer. J Nucl Med 45:2058–2062

    PubMed  Google Scholar

  3. Sahoo MK, Sharma P, Suman S, Jain TK, Bal C, Kumar R (2014) Gallbladder carcinoma metastasizing to adrenal gland: a rare site demonstrated with (18)F-FDG PET/CT. Clin Nucl Med 39:184–185

    Article  Google Scholar

  4. Bertagna F, Biasiotto G, Rodella C, Werner T, Giubbini R, Alavi A (2009) Massive bilateral adrenal gland metastases from melanoma diagnosed by F18-FDG-PET/CT. Jpn J Radiol 27:392–393

    Article  Google Scholar

  5. Matsumoto S, Hosoya Y, Lefor AK et al (2018) A black adrenal adenoma with high FDG uptake on PET/CT scan in a patient with esophageal carcinoma: a case report. Int J Surg Case Rep 44:118–121

    Article  Google Scholar

  6. Cisbro A, Asabella AN, Copollina P et al (2015) Diagnostic and prognostic value of F-18 FDG PET/CT in comparison with morphological imaging in primary adrenal gland malignancies-a multicenter experience. Hell J Nucl Med 18:97–102

    Google Scholar

  7. Wong KK, Miller BS, Viglianti BL et al (2016) Molecular imaging in the management of adrenocortical carcinoma. Clin Nucl Med 41:e368–e382

    Article  Google Scholar

  8. Lin Y, Jeng LB, Wong HY, Tsai SC, Lin WY, Kao CH (2015) Clinical value of F-18 FDG PET/CT in detecting adrenal metastasis in patients with hepatocellular carcinoma. Technol Cancer Res Treat 14:593–599

    Article  CAS  Google Scholar

  9. Yoo SW, Kim DY, Pyo A, Jeon S, Kim J, Kang SR, Cho SG, Lee C, Kim GJ, Song HC, Bom HS, Min JJ, Kwon SY (2021) Differences in diagnostic impact of dual-tracer PET/computed tomography according to the extrahepatic metastatic site in patients with hepatocellular carcinoma. Nucl Med Commun 42:685–693

    Article  CAS  Google Scholar

  10. Babaya N, Noso S, Hiromine Y, Taketomo Y, Niwano F, Monobe K, Imamura S, Ueda K, Yamazaki Y, Sasano H, Ikegami H (2021) Oncocytic adrenocortical carcinoma with low (18)F-FDG uptake and the absence of glucose transporter 1 expression. J Endocr Soc 5:bvab143

    Article  Google Scholar

  11. Turlakow A, Yeung HW, Salmon AS, Macapinlac HA, Larson SM (2003) Peritoneal carcinomatosis: role of (18)F-FDG PET. J Nucl Med 44:1407–1412

    PubMed  Google Scholar

  12. Becherer A, Vierhapper H, Pötzi C et al (2001) FDG-PET in adrenocortical carcinoma. Cancer Biother Radiopharm 16:289–295

    Article  CAS  Google Scholar

  13. Perri M, Erba P, Volterrani D, Guidoccio F, Lazzeri E, Caramella D, Mariani G (2011) Adrenal masses in patients with cancer: PET/CT characterization with combined CT histogram and standardized uptake value PET analysis. AJR Am J Roentgenol 197:209–216

    Article  Google Scholar

  14. Launay N, Silvera S, Terenbaum F et al (2015) Value of F-18 FDG PET/CT and CT in the diagnosis of indeterminate adrenal masses. Int J Endocrinol 2015:213875

    Article  Google Scholar

  15. Vos EL, Grewal RK, Russo AE, Reidy-Lagunes D, Untch BR, Gavane SC, Boucai L, Geer E, Gopalan A, Chou JF, Capanu M, Strong VE (2020) Predicting malignancy in patients with adrenal tumors using (18) F-FDG-PET/CT SUVmax. J Surg Oncol 122:1821–1826

    Article  Google Scholar

  16. Saito H, Shuto K, Ota T et al (2010) A case of long term survival after surgical resection for postoperative solitary adrenal metastasis from esophageal adenocarcinoma. Gan To Kagaku Ryoho 37:2406–2408

    PubMed  Google Scholar

  17. Drouet C, Morel O, Boulahdour H (2017) Bilateral huge incidentalomas of isolated adrenal metastases from unknown primary melanoma revealed by F-18 FDG PET/CT. Clin Nucl Med 42:e51-53

    Article  Google Scholar

  18. Arons MS, Smith RR (1961) Distant metastases and local recurrence in head and neck cancer. Ann Surg 154:235–240

    Article  CAS  Google Scholar

  19. Cedermark BJ, Blumenson LE, Pickren JW, Elias EG (1977) The significance of metastases to the adrenal gland of the stomach and esophagus. Surg Gynecol Obstetrics 145:41–48

    CAS  Google Scholar

  20. Omata H, Kono K, Sugai H, Kumamoto H, Fuji H (2005) A case of esophageal cancer with synchronous intragastric wall metastasis and adrenal metastasis. J Jpn Surg Assoc 66:2870–2876

    Article  Google Scholar

  21. Nagano H, Ichikawa W, Yoshida Y, Hirayama R, Ishizawa K, Ban S (2004) Resection of metastatic left adrenal gland tumor from carcinoma of thoracic esophagus. Gastroenterol Surg 27:1213–1217

    Google Scholar

  22. Furukawa K, Yoshitoshi K, Eguchi R (2012) A long survival case of metastatic left adrenal gland tumor from undifferentiated carcinoma of thoracic esophagus. J Jpn Coll Surg 37:248–251

    Google Scholar

  23. Kim SJ, Lee SW, Pak K, Kim IJ, Kim K (2018) Diagnostic accuracy of 18F-FDG PET or PET/CT for the characterization of adrenal masses: a systematic review and meta-analysis. Br J Radiol 91:20170520

    Article  Google Scholar

  24. Tu W, Verna R, Krishna S, Melnnes MDF, Flood TA, Schieda N (2018) Can adrenal adenomas be differentiated from adrenal metastases at single-phase contrast-enhanced CT? AJR Am J Roentgenol 79:149–152

    Google Scholar

  25. Lee HJ, Lee J (2014) Differential diagnosis of adrenal mass using imaging modality: special emphasis on F-18 fluoro-2-deoxy-D-glucose positron emission tomography/computed tomography. Endocrinol Metob 29:5–11

    Article  Google Scholar

  26. Altinmakas E, Hobbs BP, Ye H et al (2017) Diagnostic performance of 18-F-FDG-PET-CT in adrenal lesions using histopathology as reference standard. Abdom Radiol (NY) 42:577–584

    Article  Google Scholar

  27. Choudhury S, Purandare N, Agrawal A, Shah S, Rangarajan V (2018) FDG PET-CT in adrenal multiple myeloma. Clin Nucl Med 43:691–692

    Article  Google Scholar

  28. Altinmakas E, Üçışık-Keser FE, Medeiros LJ, Ng CS (2019) CT and 18F-FDG-PET-CT findings in secondary adrenal lymphoma with pathologic correlation. Acad Radiol 26:e108–e114

    Article  Google Scholar

Download references

Acknowledgements

Not applicable.

Funding

Not applicable

Author information

Authors and Affiliations

  1. Department of Nuclear Medicine, Mersin University Medical Faculty, 33343, Mersin, Turkey

    Zehra Pınar Koç & Pınar Pelin Özcan

  2. Department of Oncology, Mersin University Medical Faculty, Mersin, Turkey

    Emel Sezer & Kadir Eser

  3. Department of Pathology, Mersin University Medical Faculty, Mersin, Turkey

    Tuba Kara

Authors
  1. Zehra Pınar Koç
    View author publications

    You can also search for this author in PubMed Google Scholar

  2. Pınar Pelin Özcan
    View author publications

    You can also search for this author in PubMed Google Scholar

  3. Emel Sezer
    View author publications

    You can also search for this author in PubMed Google Scholar

  4. Kadir Eser
    View author publications

    You can also search for this author in PubMed Google Scholar

  5. Tuba Kara
    View author publications

    You can also search for this author in PubMed Google Scholar

Contributions

All authors read and approved the final manuscript.

Corresponding author

Correspondence to Zehra Pınar Koç.

Ethics declarations

Ethics approval and consent to participate

Not applicable.

Consent for publication

Not applicable.
