Unexpected septic pulmonary embolism imaging with 18-F FDG PET/CT in an infective endocarditis case: case report

Abstract

Background

Infective endocarditis (IE) is a severe disease that is diagnosed using a combination of clinical, microbiologic, and imaging criteria (modified Duke criteria). The prognosis relies on the degree of valvular involvement and crucially the presence of systemic infectious embolism. We present an educational infective endocarditis case with images of 18-F fluoro-D-glucose positron emission tomography/computed tomography (18-F FDG PET/CT) showing hypermetabolic lesions on the prosthetic tricuspid valve and papillary muscle of right ventricle. Besides these lesions, PET/CT showed an unexpected hypermetabolic extra-cardiac focus.

Case presentation

A 36-year-old male patient with IE history was underwent 18-F FDG PET/CT imaging. FDG PET revealed hypermetabolic lesions on the prosthetic tricuspid valve and papillary muscle of right ventricle. Besides these lesions, PET/CT showed an unexpected hypermetabolic focus in the lower lobe of the right lung, which was consistent with septic pulmonary embolism.

Conclusions

18-F FDG PET/CT is a valuable, noninvasive imaging modality in diagnosis of prosthetic valve IE. It could change treatment planning since detecting extra-cardiac lesions.

Background

The diagnosis of infective endocarditis (IE) is based on modified Duke criteria. However, it is known that the present criteria have low sensitivity for the diagnosis of prosthetic valve endocarditis. The prognosis of IE is closely associated with the extra-cardiac complications (ECC), embolic events and metastatic infections. ECC incidence was reported as 20–50% [1,2,3].

Case presentation

A 36-year-old male patient without previous cardiac history presented with fever. Based on laboratory test results and Transthoracic/transesophageal echocardiography (TEE) findings, the patient was diagnosed with native tricuspid valve IE. In this patient, the only risk factor for IE was a tattoo done under non-sterile conditions. The patient had been operated, and a prosthetic valve was implanted. Histopathological examination was consistent with active endocarditis. Staphylococcus epidermidis and Staphylococcus warneri were detected in the microbiological culture. Staphylococcus warneri normally occurs on human skin and is often considered contamination when detected in blood cultures. However, rarely it can cause IE.

One year later, the patient applied to our clinic again with the complaint of fever. A 1.7 × 0.5 cm hyperechoic, oscillatory mass was revealed by TEE on the septal leaflet of the prosthetic valve. Blood cultures were negative. 18-Fluoro fluoro-D-glucose positron emission tomography/computed tomography (18-F FDG PET/CT) scan was planned to confirm prosthetic valve endocarditis. The patient was instructed to maintain a low carbohydrate and fat-rich diet a day before the imaging to suppress physiologic cardiac FDG uptake. The PET/CT scan (Discovery 600, GE Medical Systems, Milwaukee, WI, USA) was performed 60 min after intravenous injection of 4 MBq/kg dose of 18F FDG. During CT examination, 80 mL of contrast agent (Ultravist 300, Schering AG, Berlin, Germany) was administered. Both uncorrected and attenuation-corrected images were assessed in order to identify any artifacts caused by contrast agent, tricuspid valve implant, or cardiac/respiratory motion. PET images revealed hypermetabolic lesions on septal leaflet of tricuspid valve, which was extended to the papillary muscle (Fig. 1). In addition, an unexpected mild hypermetabolic lesion was observed on the pulmonary artery branch of the right lung lower lobe posterobasal segment (Fig. 1 cont.), which was verified as septic embolism in the CT pulmonary angiography (Fig. 2). After reoperation, histopathological and microbiological samples confirmed the diagnosis of Chaetomium globosum infection. The patient was successfully treated with antibiotics, antimycotic and anticoagulation therapy. One month later, control TEE did not show any lesion.

Fig. 1
figure 1

18F FDG PET/CT images showing hypermetabolic lesions in the prosthetic tricuspid valve (arrows) and papillary muscle of the right ventricle (arrow heads). Beside these lesions, PET images revealed a less intensity focal FDG uptake in the pulmonary artery branch of the right lung lower lobe, which was consistent with septic pulmonary emboli (asterisk) (a axial plane, b: coronary plane). MIP: Maximum intensity projection

Fig. 2
figure 2

CT pulmonary angiography revealed filling defects (arrow) of pulmonary artery branch supplying right lower lobe, consistent with pulmonary emboli (a:sagittal plane, b:coronary plane, c:axial plane)

Conclusions

Larger vegetation occurs in cases of right-sided IE due to a delay in diagnosis [4, 5]. Complications in these cases are usually related to embolic events [5]. According to the guidelines, FDG PET/CT may help reduce the number of misdiagnosed IE classified in the “possible” category of the modified Duke criteria and aid in visualizing peripheral embolism and metastatic infective events [6]. Additional extra-cardiac foci detected 17% of patients in PET/CT [7]. Based on the extra-cardiac findings on FDG PET/CT, the incidence of relapsed IE has been reported to be significantly reduced [8]. FDG PET/CT provides promising results in the treatment of patients with IE.

However, it should be kept in mind that peripheral homogeneous radioactivity uptake could be seen at non-infected prosthetic valve which is associated with the physiological scarring process around the prosthesis [9]. This uptake is more obvious on attenuation-corrected PET images. Infected prosthesis should be added to the differential diagnosis when obviously increased uptake of activity with heterogeneous distribution in the periphery of the prosthesis is detected.

In the current case, the FDG PET/CT revealed the undetected lesion by clinical/laboratory findings and other imaging modalities.

Availability of data and materials

Contact the corresponding author for data requests.

Abbreviations

IE:

Infective endocarditis

18-F FDG PET/CT:

18-F Fluoro-D-glucose positron emission tomography/computed tomography

ECC:

Extra-cardiac complications

TEE:

Transesophageal echocardiography

References

  1. Jaffe WM, Morgan DE, Pearlman AS, Otto CM (1990) Infective endocarditis 1983–1988: echocardiographic findings and factors influencing morbidity and mortality. J Am Coll Cardiol 15:1227–1233

    Article  CAS  PubMed  Google Scholar

  2. Millaire A, Leroyf O, Gaday V, de Groote P, Beuscart C, Goullard L et al (1997) Incidence and prognosis of embolic events and metastatic in-fections in infective endocarditis. Eur Heart J 18:677–684

    Article  CAS  PubMed  Google Scholar

  3. Habib G, Hoen B, Tornos P, Thuny F, Prendergast B, Vilacosta I et al (2009) ESC committee for practice guidelines (CPG). Guidelines on the prevention, diagnosis, and treatment of infective endocarditis (new version 2009): the task force on the prevention, diagnosis, and treatment of infective endocarditis of the european society of car-diology (ESC). Eur Heart J 30:2369–2413

    Article  PubMed  Google Scholar

  4. Weber C, Gassa A, Eghbalzadeh K, Merkle J, Djordjevic I, Maier J et al (2019) Characteristics and outcomes of patients with right-sided endocarditis undergoing cardiac surgery. Ann Cardiothorac Surgc 8:645–653

    Article  Google Scholar

  5. Holland TL, Baddour LM, Bayer AS, Hoen B, Miro JM, Fowler WG Jr (2016) Infective endocarditis. Nat Rev Dis Primers 2:16059

    Article  PubMed  PubMed Central  Google Scholar

  6. Habib G, Lancellotti P, Antunes MJ, Bongiorni MG, Casalta JP, Del Zoti F (2015) 2015 ESC Guidelines for the management of infective endocarditis: the task force for the management of infective endocarditis of the European society of cardiology (ESC). endorsed by: European association for cardio-thoracic surgery (EACTS), the European association of nuclear medicine (EANM). Eur Heart J 36:3075–3128

    Article  PubMed  Google Scholar

  7. Mahmood M, Kendi AT, Ajmal S, Farid S, O’Horo JC, Chareonthaitawee P et al (2019) Meta-analysis of 18F-FDG PET/CT in the diagnosis of infective endocarditis. J Nucl Cardiol 26:922–935

    Article  PubMed  Google Scholar

  8. Kestler M, Munoz P, Rodrıguez-Creixems M, Rotger A, Jimenez-Requena F, Mari A et al (2014) Role of (18)F-FDG PET in patients with infective endocarditis. J Nucl Med 55:1093–1098

    Article  CAS  PubMed  Google Scholar

  9. Mathieu C, Mikail N, Benali K, Lung B, Duval X, Nataf P et al (2017) Characterization of 18F-fluorodeoxyglucose uptake pattern in noninfected prosthetic heart valves. Circ Cardiovasc Imaging 10:e005585

    Article  PubMed  Google Scholar

Download references

Acknowledgements

Not applicable.

Funding

Not applicable.

Author information

Authors and Affiliations

Authors

Contributions

The study was designed by EA. Material preparation and data collection were performed by EA and RA. The data analysis was performed by EA. The first draft of the manuscript was written by EA, and all authors commented on previous versions of the manuscript. All authors read and approved the final manuscript.

Corresponding author

Correspondence to Elife Akgun.

Ethics declarations

Ethics approval and consent to participate

This case report was not need ethics committee approval due to retrospective design. All authors certify that the study was performed in accordance with the ethical standards as laid down in the Helsinki declaration as revised in 2013.

Consent for publication

Written informed consent was obtained from the patient for publication of this case report and accompanying images.

Competing interests

The authors declare that they have no competing interests.
