Primary pancreatic Ewing sarcoma with metastases on FDG PET/CT



Ewing sarcoma (ES) is a highly aggressive malignant tumor most commonly affecting long bones. Extraskeletal Ewing sarcoma (EES) is a malignant tumor with aggressive behavior carrying bad prognosis with pancreas being an extremely rare primary site. We present a case of histopathologically proven EES of the pancreas in a young female who presented with abdominal pain. 18F-fluorodeoxyglucose positron emission tomography (18F FDG PET/CT) is a useful modality for detecting distant metastases in EES. It helps in diagnosis, localizing the primary, its extension, optimal treatment planning and evaluation of response to standard treatments available.

Case presentation

An 18-year-old female presented with complaints of progressive abdominal pain and distention since 6 weeks. Physical examination was suggestive of a solid large mass in the upper left abdomen and decreased breath sounds with dullness in the left lower lung fields. On Contrast enhanced computed tomography (CECT) imaging, a large heterogeneously enhancing mass was seen arising from pancreas along with retroperitoneal lymphadenopathy. A moderate sized left sided pleural effusion with atelectasis of lower lobe of left lung was also noted. Histopathological analysis was suggestive of pancreatic ES following which the patient underwent five cycles of chemotherapy. Following this, she underwent 18F FDG PET/CT which showed hypermetabolic large mass arising from body and tail of pancreas with areas of internal necrosis along with left adrenal metastasis, retroperitoneal lymphadenopathy, a massive left pleural effusion and compressive atelectasis of left lower lobe. The patient expired within a week following PET/CT.


EES most often presents in the late stage of the disease with vague symptoms. Timely diagnosis and initiation of treatment is of utmost importance considering the aggressiveness of the tumor. Establishing a diagnosis of Ewing sarcoma is especially difficult when the mass is arising from the pancreas. Imaging, histopathology and immunohistochemistry (IHC) play a key role in accurate diagnosis of such masses. 18F FDG PET/CT can be useful for detecting local and distant spread, operability, treatment planning and evaluation of response to chemotherapy.


In 1921, James Ewing first described Ewing sarcoma and thereafter in 1969, Tefft described about extraosseous Ewing sarcoma/primitive neuroectodermal tumor (ES/PNET) [1, 2]. ES/PNET has unusual involvement sites such as the oral cavity, salivary glands, esophagus, stomach, lung, heart, biliary tract, pancreas and genitourinary system. The pancreas is a very rare primary site, with few cases that have been reported globally [3]. EES is a rare entity and less is known about its clinical behavior and optimal treatment than for its counterpart in bone [4]. PET/CT has been identified as a useful modality for detecting distant metastases in extraskeletal Ewing sarcoma. It helps to localize the primary, its extension, distant metastatic sites and to check the treatment response.

Here, we present a rare case of primary pancreatic Ewing sarcoma with retroperitoneal lymph nodes who underwent PET/CT scan for disease status evaluation. Patient expired after taking the first line of chemotherapy after PET/CT. Time between the clinical presentation and final diagnosis to start treatment was approximately 3 months.

Case presentation

An 18-year-old female presented to gastroenterology department with complaints of a dull aching and progressive upper abdominal pain radiating to the upper back for 8 weeks along with bloating and nausea. This was accompanied by rapidly progressive distention of the upper half of abdomen for 4 weeks. On general physical examination, the patient appeared pale and lethargic. The left upper half of her abdomen was grossly distended and the umbilicus was shifted to the right. On palpation of the abdomen, a hard ill-defined fixed mass was felt in the hypogastrium which did not move with respiration. The deeper extent of the mass could not be assessed by clinical examination. Her trachea was shifted to the right along with decreased breath sounds and dullness on percussion in left lung fields. Normal breath sounds were heard on the right. As a part of initial evaluation, patient was advised a CT study of the thorax and abdomen. It showed a 15.7 × 10.5 × 9.1 cm large lobulated heterogeneously enhancing predominantly solid exophytic mass arising from the body and tail of pancreas extending into gastrosplenic space superiorly and left upper retroperitoneal space inferiorly. It was found compressing the greater curvature of the stomach superomedially, the spleen superolaterally, the left kidney inferiorly and also the splenic and the left renal vessels. Multiple small sized retroperitoneal lymph nodes, largest being 13.0 × 9.5 mm, were also noted. Thorax images showed a moderate sized pleural effusion with contralateral shift of the mediastinum and passive atelectasis of the left lower lobe. CT guided biopsy of the abdominal mass showed the presence of fibrocollagenous tissue stroma infiltrated by small round tumor cells with round nuclei with finely stippled chromatin and scant eosinophilic cytoplasm. Homer Wright pseudorosettes were also identified comprising of central fibrillary core surrounded by concentrically arranged tumor cells. Immunohistochemistry examination was strongly and diffusely positive for CD99 and Vimentin and negative for LCA, CK, CD56, Synaptophysin, WT1, INHIBIN, Myogenin, EMA, Desmin and S100 (Fig. 1). Based on the above findings, a diagnosis of pancreatic Ewing sarcoma was made, following which the patient underwent five cycles of first line chemotherapy comprising of vincristine, doxorubicin and cyclophosphamide. She was then referred to Nuclear Medicine department for 18F FDG PET/CT which showed a hypermetabolic well defined heterogeneously enhancing large lobulated mass (~ 17.7 × 16.1 × 23.7 cm, SUVmax 17.6) with areas of internal necrosis involving body and tail of pancreas. The fat planes with the adjacent left kidney were lost with compression of splenic and left renal vessels. Metabolically active preaortic (SUVmax 12.6), paraaortic and right common iliac lymphadenopathy were noted, the largest being the preaortic lymph nodes. Metabolically active left adrenal (SUVmax 11.2) metastasis was also noted. There was massive left pleural effusion resulting in passive atelectasis of the lower lobe left lung and ascites was also noted (Fig. 2, 3 and 4). Unfortunately, around one week after the patient underwent PET/CT, the patient succumbed to the disease.

Fig. 1
figure 1

Hematoxylin and eosin stain: showing monotonous population of small round cells and tumor cells arranged in sheets and rosettes (200X) (A), Homer Wright rosettes (arrow) consist of a central neutrophil surrounded by concentrically arranged tumor cells (400X) (B), Vimentin: strong diffuse staining in tumor cells (400X) (C) and CD99: strong and diffuse membranous staining in tumor cells (400X) (D)

Fig. 2
figure 2

A 20-year-old female, presented with left sided abdominal distention (A) and upper abdominal pain for 8 weeks. Maximum intensity projection (MIP) image of 18F FDG PET scan shows a large area of tracer uptake in the left side of the abdomen (B)

Fig. 3
figure 3

Axial, coronal and sagittal CT and corresponding PET/CT images (A, B and C) showing metabolically active large heterogeneously enhancing lobulated mass (arrow) arising from body and tail of the pancreas with areas of internal necrosis, right pleural effusion (arrowhead) with passive atelectasis of right lung (in coronal and sagittal images). CT and corresponding PET/CT images showing metabolically active paraaortic lymph node (D)

Fig. 4
figure 4

Axial, coronal and sagittal CT and corresponding PET/CT images (A, B and C) showing metabolically active pancreatic mass (yellow arrow) along with relatively less metabolically active (as compared to pancreatic mass) left adrenal metastasis (red arrow)


Primary pancreatic Ewing sarcoma is a very rare tumor. It should be considered in the differential diagnosis of an unusual pancreatic tumor especially in young adults. EES has an aggressive clinical course and early distant metastases [5].Usually presentation of EES patients is with bone, liver and lung involvement along with lymph nodal metastasis at time of diagnosis. Imaging plays a central role in the diagnosis, staging, restaging, treatment response and surveillance of EES. Conventional imaging (like CT, MRI etc.) can diagnose only 70% of the cases with distant metastasis [6]. MRI is the preferred imaging modality for primary tumor evaluation, diagnosis and local staging, while FDG PET/CT is used to detect metastatic disease. PET/CT is sensitive (87%) and specific (97%) for detecting distant metastasis with an accuracy of 94% [7].

FDG PET/CT helps localizing primary, staging and to check the response to standard treatment available. It also helps restating of disease and detection of recurrence prior to anatomic imaging [8,9,10]. Usually, EES are aggressive and often unresectable tumors having distant metastasis at the time of diagnosis. Hence, PET/CT is useful modality detect distant metastases in such cases [11] and post-surgical recurrence with extremely high accuracy. PET/CT also provides the prognostic data.

Histopathology and immunohistochemistry are essential for making final diagnosis. It indicates need for early diagnosis and prompt treatment. Moreover, early definitive diagnosis of ES/PNET can produce better survival with current treatment modalities. Few studies have quoted that the prognosis of EES is more favorable compared to the skeletal subtype [12, 13]. The 5-year overall survival rate is superior for localized EES compared with localized skeletal Ewing sarcoma [14]. As PET/CT is valuable imaging method for diagnosis and staging of such patients, so it is time saving in initial diagnostic workup and initiation of treatment. PET/CT detects the tumor regression or progression before anatomical imaging like CT and MRI as functional/metabolic changes precede structural changes. PET/CT findings during therapy or after completion can aid in decision-making about continuation or change in treatment plan.

PET/CT helps in change in treatment plan in ESS [15]. There is paucity of literature on this because of rarity of EES and availability of PET/CT also matters.

Although in our case we had contradictory finding to the previous authors about the prognosis of EES [12, 13]. EES usually have vague or general symptoms. EES are aggressive tumors, often diagnosed in advanced stage and have poor prognosis. The probable reason behind the poor prognosis among these patients is that there is lagging in onset of symptoms to usual time of diagnosis; therefore, they are present with multiple metastatic sites and large tumor size at the time of diagnosis. In EES, tumor size is a predictor of overall survival. Tumor size ≥ 8 cm is a significant predictor of worse overall survival as reported by Tural et al. [16]. We have previously reported two cases of EES who died before the treatment initiation [8, 15] and the present case also has a very similar scenario. All patients had large tumor size and multiple metastases. These patients require prompt and aggressive imaging and cytogenetic evaluation to reduce the time between onset of symptoms to usual time of diagnosis. It should be kept as primary differentials as these patients have vague symptoms, nonspecific imaging features and poor prognosis. PET/CT helps in early diagnosis, optimal treatment initiation as well as metabolic response to treatment before the anatomical changes.


Extraskeletal ES/PNET is a rare disease. The physicians, radiologist, as well as pathologists often face diagnostic dilemma because of vague signs and symptoms and nonspecific radiological features. Extraskeletal ES/PNET should be considered in the differential diagnosis of intraabdominal and extraintestinal masses. This problem is significantly critical when the tumor site of origin is rare, such as the pancreas. The 18F FDG PET/CT helps in diagnosis, staging, treatment planning, restaging, response evaluation and prognostication of EES. The timely and aggressive use of multimodality imaging, histopathology and immunohistochemistry aids in accelerating the diagnosis thus leading to an earlier treatment for a better outcome.

Availability of data and material

The dataset used and/or analyzed during the current study available from the corresponding author on the reasonable request.



Extraskeletal Ewing sarcoma/primitive neuroectodermal tumor


Ewing sarcoma


Extraskeletal Ewing sarcoma


Positron emission tomography


Contrast enhanced computed tomography


Magnetic resonance imaging




  1. Ludwig JA (2008) Ewing sarcoma: historical perspectives, current state-of-the-art, and opportunities for targeted therapy in the future. Curr Opin Oncol 20(4):412–418

    Article  PubMed  Google Scholar

  2. Crist WM, Raney AB, Tefft M, Heyn R, Hays DM, Newton W, Beltangady M, Maurer HM (1985) Soft tissue sarcomas arising in the retroperitoneal space in children a report from the intergroup rhabdomyosarcoma study (IRS) committee. Cancer 56(8):2125–2132

    Article  CAS  PubMed  Google Scholar

  3. Yohannan B, Feldman M (2020) A nonpediatric extraosseous Ewing sarcoma of the pancreas: differential diagnosis and therapeutic strategies. Case Rep Oncol Med 30:2020

    Google Scholar

  4. Livellara V, Bergamaschi L, Puma N, Chiaravalli S, Podda M, Casanova M, Gasparini P, Pecori E, Alessandro O, Nigro O, Sironi G (2022) Extraosseous Ewing sarcoma in children and adolescents: a retrospective series from a referral pediatric oncology center. Pediatr Blood Cancer 69(5):e29512

    Article  CAS  PubMed  Google Scholar

  5. Golhar A, Ray S, Haugk B, Singhvi SK (2017) Cytogenetically confirmed primary Ewing’s sarcoma of the pancreas. Case Rep 2017:bcr-2017

    Google Scholar

  6. Ozturk H (2015) Peripheral neuroectodermal tumour of the kidney (Ewing’s sarcoma): Restaging with 18F-fluorodeoxyglucose (FDG)-PET/CT. Can Urol Assoc J 9(1–2):E39

    Article  PubMed  PubMed Central  Google Scholar

  7. Abboud A, Masrouha K, Saliba M, Haidar R, Saab R, Khoury N, Tawil A, Saghieh S (2021) Extraskeletal Ewing sarcoma: diagnosis, management and prognosis. Oncol Lett 21(5):1–6

    Article  Google Scholar

  8. Singh MM, Verma S, Thakur PB, Kakkar L, Deswal S (2023) Posterior mediastinal Ewing sarcoma with multiple metastases on FDG PET/CT: a rare entity. Egypt J Radiol Nucl Med 54(1):1–5

    Google Scholar

  9. Seth N, Seth I, Bulloch G, Siu AH, Guo A, Chatterjee R, MacManus M, Donnan L (2022) 18F-FDG PET and PET/CT as a diagnostic method for Ewing sarcoma: a systematic review and meta-analysis. Pediatr Blood Cancer 69(3):e29415

    Article  PubMed  Google Scholar

  10. Huang T, Li F, Yan Z, Ma Y, Xiong F, Cai X, Zhang Q, Liu F, Dong J (2018) Effectiveness of 18F-FDG PET/CT in the diagnosis, staging and recurrence monitoring of Ewing sarcoma family of tumors: a meta-analysis of 23 studies. Medicine 97(48)

  11. Zheng C, Zhou Y, Luo Y, Zhang H, Tu C, Min L (2021) Case report: primary Ewing sarcoma of the penis with multiple metastases. Front Pediatr 7(8):591257

    Article  Google Scholar

  12. Cash T, McIlvaine E, Krailo MD, Lessnick SL, Lawlor ER, Laack N, Sorger J, Marina N, Grier HE, Granowetter L, Womer RB (2016) Comparison of clinical features and outcomes in patients with extraskeletal versus skeletal localized Ewing sarcoma: a report from the Children’s Oncology Group. Pediatr Blood Cancer 63(10):1771–1779

    Article  CAS  PubMed  PubMed Central  Google Scholar

  13. Lynch AD, Gani F, Meyer CF, Morris CD, Ahuja N, Johnston FM (2018) Extraskeletal versus skeletal Ewing sarcoma in the adult population: controversies in care. Surg Oncol 27(3):373–379

    Article  PubMed  Google Scholar

  14. Applebaum MA, Worch J, Matthay KK, Goldsby R, Neuhaus J, West DC, DuBois SG (2011) Clinical features and outcomes in patients with extraskeletal Ewing sarcoma. Cancer 117(13):3027–3032

    Article  PubMed  Google Scholar

  15. Singh MM, Verma S, Kakkar L, Deswal S, Husain N (2023) Ewing’s sarcoma of the right kidney with multiple metastasis on PET/CT. Egypt J Radiol Nuclear Med 54(1):1–5

    Google Scholar

  16. Tural D, Molinas Mandel N, Dervisoglu S, OnerDincbas F, Koca S, ColpanOksuz D, Kantarci F, Turna H, Selcukbiricik F, Hiz M (2012) Extraskeletal Ewing’s sarcoma family of tumors in adults: prognostic factors and clinical outcome. Jpn J Clin Oncol 42(5):420–426. (Epub 2012 Mar 12)

    Article  PubMed  Google Scholar
