MRI for assessment of pathologic nipple discharge: is it mandatory?
Egyptian Journal of Radiology and Nuclear Medicine volume 50, Article number: 92 (2019)
Benign breast lesions is the most common cause of nipple discharge; however, a rare but major cause is breast cancer. This study assesses the superadded value of MRI in diagnosing causes of pathologic nipple discharge. Ninety-three patients with pathologic nipple discharge were evaluated by sonomammography and DCE-MRI. Sonomammography and MR imaging features were analyzed and correlated with the histopathology.
Histopathology revealed 69 benign, three high-risk, and 21 malignant lesions. Simply dilated ducts and presence of a mass on US examination as well as non-mass enhancement and STIR signal changes on MRI were of statistically significant probability in differentiation between benign and malignant causes of pathological nipple discharge (p value = 0.017 and 0.001) and (p value ≤ 0.001). Sensitivity and specificity of mammogram and ultrasound in differentiation between benign and malignant causes of pathologic nipple discharge were 71.4% and 54.2% respectively with positive predictive value of 31.2%,negative predictive value of 86.7%, and accuracy of 58.1%. MRI gave higher sensitivity and specificity of 100% and 83.3% with positive predictive value of 63.6%, negative predictive value of 100%, and accuracy of 87.1%.
Magnetic resonance imaging is superior to sonommagraphy in diagnosis of pathologic nipple discharge and we recommend it in special situations.
Pathologic nipple discharge is characterized by spontaneous secretions from unilateral single or several ducts. A clear or bloody discharge is of major significance due to its higher association with breast masses . Benign conditions such as papilloma or ductal ectasia are the commonest causes of most unilateral bloody nipple discharge. A rare but major cause of spontaneous pathologic nipple discharge (SPND) is breast cancer which accounts for 7–33% of the cases .
Traditional imaging methods used in the diagnostic approach to SPND are mammography and ultrasonography (US). Mammography is of limited use in cases of bloody nipple discharge, as it is often negative and fails to suggest the causative lesion. Not always microcalcifications associate the underlying process and sometimes masses are so small, so the sensitivity of mammography in these cases is inadequate .
Ultrasound of the breasts should be conducted in addition to mammography, as this modality allows for the detection of intraductal papilloma, particularly with the use of high-frequency probes (11–13 MHz) .
Magnetic resonance imaging (MRI) is a valuable adjunctive means of detecting and diagnosing papillomas and malignancies especially invasive ductal carcinoma and ductal carcinoma in situ (DCIS), especially in cases when the other two modalities are normal. In recent years, MRI has increased in importance in high-risk patients with nipple discharge and in patients with suspicious nipple discharge .
Our aim in this study was to determine the added value of dynamic contrast-enhanced MRI in diagnosis of different causes of pathologic nipple discharge.
This is an institutional review board approved prospective study carried out in the period between January 2015 and August 2018. The study was conducted on 93 females complaining of spontaneous nipple discharge, their ages ranging from 27 to 70 years old with mean age of 49.74 ± 11.81. All patients gave an informed consent before inclusion in the study. Patients were subjected to full clinical examination, sonomammographic evaluation, post contrast dynamic MRI, and pathological evaluation. The inclusion criteria include non-lactating female complaining from spontaneous nipple discharge. The exclusion criteria were induced nipple discharge, any patient with contraindication for doing MRI, and pregnant female not candidate for mammography or post contrast MRI. Patients’ demographics, nature, and side of the pathologic nipple discharge are described on Table 1.
Mammographic examinations were performed for only 84 patients (as the remaining nine patients were younger than 30 years old) using a LABDA/GMI (General Medical Italy) mammography system (LABDA/GMI, Italy). Standard craniocaudal (CC) and mediolateral oblique (ML) views were routinely obtained, and additional mammographic views were used as needed. The mammograms were assessed for the presence of mass (localized abnormal density), focal asymmetry, and calcifications.
Breast US was performed by 10-year experienced radiologist (MMZ) using a scanner with 5–12 MHz linear-array transducers. US of both breasts was performed first by scanning each breast in the transverse and sagittal orientations, inner aspect of the breast in a supine position, and outer aspect in supine oblique position with the patient’s arm raised above the head. The radiologist assessed the presence of breast masses, the lactiferous ducts and periductal area, and the axillary tail followed by scanning the axilla. In cases of palpable abnormality, targeted scanning at the area of concern was performed. US were assessed for presence of duct ectasia whether it is a simple duct ectasia or having echogenic content inside and intraductal breast masses. Masses were assessed for their number, size, shape, margin, echogenicity, and their distance from the nipple. Doppler scanning of the detected lesions was done to assess their internal vascularity.
MRI examinations were performed on a 1.5-T system with a dedicated four-channel phased-array bilateral breast coil (Achieva, Philips Medical Systems, Best, the Netherlands). All patients were examined in the prone position with their arms elevated above the head. MR protocols include T1WI (TR 512 ms, TE 8 ms, slice thickness 3 mm, FOV 400–500 mm, and matrix was 256 × 256), T2WI (TR 2000 ms, TE 8 ms, slice thickness 80 mm, FOV 400–500 mm, and matrix was 256 × 256, flip angel 90°), and STIR (TR 4000 ms, TE 70 ms and TI was 175 ms, slice thickness was 3 mm with inter slice gap 1 mm, FOV400–500 mm, and the matrix was 256 × 256 were obtained). Dynamic images were taken after the administration of the contrast agent at 0.2 mmol/L per kilogram of body weight. Post contrast series, 1.16 min was the time between each study with 20-s break between the pre contrast and post contrast. Then a ROI was placed carefully within the most enhancing part of the lesion. The size of the ROIs were chosen in a lesion varied with the size and the shape of the lesion. MRI examination were analyzed by more than 15 years experienced radiologist (NYS) blinded from the sonomammographic findings for abnormal STIR signal intensity; presence of ductal, mass, or non-mass enhancement; shape; and size of detected lesions.
Statistical analysis of the data
We correlated the sonomammographic and MRI findings with pathological findings and compared sensitivity and specificity between sonomammography and MRI in detection of the underlying breast lesion.
Data were analyzed with SPSS® V. 21 (IBM Corp., New York, NY; formerly SPSS Inc., Chicago, IL). The normality of data was first tested with Shapiro test. Qualitative data were described using number and percent. Association between categorical variables was tested using Chi-square test while Fischer exact test was used when expected cell count was less than 5. Continuous variables were presented as mean ± SD (standard deviation) for parametric data and median (range) for non-parametric data. The two groups were compared with Student t test for parametric data and Mann-Whitney test for non-parametric.
The study included 93 female patients. Their age ranged from 27 to 70 years; mean age 49.7 years. All presented with nipple discharge; serous discharge (45 patients), serosanginous (15 patients), and bloody discharge (33 patients). Ultrasound and post contrast dynamic MRI were done to all patients, while mammography was done to 84 patients as the remaining nine patients were younger than 30 years old. Tissue pathology was done to all patients. Histopathological examinations revealed 69 benign lesions (74.2%), three high-risk lesions (3.2%), and 21 malignant lesions (22.6%). Benign lesions were 36 duct ectasia (38.6%), 24 duct papilloma (Fig. 1)/papillomatosis (25.8%), six fibrocystic change (6.4%), and three nipple adenoma (3.2%); high risk lesions were three atypical epithelial hyperplasia (6.4%) while malignant lesions were nine DCIS (9.7%) (Figs. 2 and 3) and 12 intraductal carcinoma IDC (12.9%) (Fig. 4). The histopathological types are summarized in Table 2.
Ultrasound findings include simple dilated ducts, ductectasia with echogenic content, postoperative changes, mottled parenchyma, and mass lesion. All patients presented by dilated ducts and echogenic contents inside were categorized as BIRADS 4a. Among these patients, 24 cases were papilloma/papillomatosis, three cases were atypical epithelial hyperplasia, while the remaining six cases were duct ectasia with inspissated secretions. On Doppler study, vascularity was seen in six cases (three papilloma and three atypical epithelial hyperplasia). Mammography was done in 30 out of 33 patients presented by ductectasia with echogenic components and different findings were detected including; dilated retroareolar duct (six patients), asymmetric density (three patients), and no abnormality could be seen in the remaining 21 patients. All cases with positive findings were categorized as BIRADS 4a. On dynamic post contrast MRI, all of 33 cases were categorized as BIRADS 3. Enhancement was seen only in 27 out of these 33 cases (pathologically proved papilloma/papillomatosis and atypical epithelial hyperplasia) including mass enhancement (12 patients), focus enhancement (six patients), or non-mass enhancement (nine patients).
Nine cases of DCIS were pathologically proved in this study. On both mammography and complementary ultrasound, three cases were categorized as BIRADS 3 and the remaining six cases were categorized as BIRADS 4b. On dynamic contrast-enhanced MRI, all cases of carcinoma in situ were categorized as BIRADS 4 and appeared as non-mass enhancement.
The remaining 12 invasive carcinomas, nine cases of them were detected by both mammogram and US as suspicious masses (BIRADS 4b and BIRDAS 4c), associated in situ component was occult in all cases by both US and mammogram, while the remaining three cases showed just postoperative changes and edema and were categorized as BIRDS 3. All cases and associated carcinoma in situ were detected by MRI and categorized as BIRADS 4. The different imaging features in sonography, mammography, and MRI are described in Tables 3, 4, and 5.
Simply dilated ducts and presence of a mass on US examination were of statistically significant probability in differentiation between benign and malignant causes of pathological nipple discharge (p value = 0.017 and 0.001). Non-mass enhancement and STIR signal changes on MRI were of high statistically significant probability in differentiation between benign and malignant causes of pathological nipple discharge (p value ≤ 0.001).
Sensitivity and specificity of mammogram and ultrasound in differentiation between benign and malignant causes of pathologic nipple discharge were 71.4% and 54.2% respectively with positive predictive value of 31.2%,negative predictive value of 86.7%, and accuracy of 58.1%,while sensitivity and specificity of 100% and 83.3% with positive predictive value of 63.6%, negative predictive value of 100%, and accuracy of 87.1%. Table 6 shows validity of MRI and sonomammography compared to pathology.
Nipple discharge accounts for 2–10% of the symptoms that women complain when they seek care at breast clinics and it is an alarming sign for both patients and clinicians since it may present sign of breast cancer . In the evaluation of PND, the limitations of sonomammography and galactography have led to further research on complementary methods such as MRI and ductoscopy . So, in the workup and management of nipple discharge, conclusions drawn about the diagnostic utility of MRI .
Our study found that benign diseases (74.2%) were the most common cause of pathologic nipple discharge, while we found high risk lesion and malignancy rate in (25.8%) of cases. Paula et al.  reported that the most common causes of nipple discharge were some benign breast lesions, such as ductal ectasia, in 6–59% of cases, and papilloma, in 35–56%. The risk of underlying malignancy is not negligible, ranging from 5 to 23%. In the current study, most (72.3%) of bloody nipple discharge was due to underlying malignant causes. Chen et al.  stated that there is association between the color of nipple discharge and breast cancer risk.
In our study, the mammographic findings in patients were as follows: asymmetric densities, dilated duct in sub areolar region, masses, and micro calcifications. Ballesio et al.  reported that mammography in patients with nipple discharge was negative in 60% of cases and also reported that the positive mammographic findings include asymmetric density, duct ectasia, and calcification.
The most common ultrasonographic features in this study were simple dilated ducts or duct ectasia with intraductal internal echoes. Ballesio et al.  found that the most common sonographic features in pathologic nipple discharge were duct dilatation, particularly associated with internal echoes and duct wall thickening. In our study, papilloma and papillomatosis on ultrasonography appeared as retroareolar dilated duct with intraductal solid internal echoes. Mammography showed no abnormality, asymmetric density, retroareolar dilated ducts, and calcification. Eiada et al.  reported that small papilloma can be occult in mammography, particularly when located in the retroareolar regions because of the breast density and relative lack of compression in that area. Dhull et al.  reported that intraductal papillomas were seen as intraductal mass lesions in all patients on sonography and MRI, while were seen in only three patients (43%) on mammography.
Lam et al.  found on US examinations dilated ducts associated with (21.7%) of their detectable papillomata. A dilated duct is a sonographic sign useful for differentiating intraductal lesions from other benign lesions such as fibroadenoma. Papilloma may present as a circumscribed hypoechoic oval nodule. In this study, papilloma on MRI appeared as enhanced focus, enhanced mass, and non-mass enhancement with different kinetics making differentiation between papilloma and carcinoma is somewhat difficult. However, previous studies reported some overlaps in MRI findings between papilloma, papillomatosis, and carcinoma [10, 13].
As regard malignant causes of pathologic nipple discharge, mammographic findings of DCIS in our study were suspicious masses, focal asymmetry with or without calcifications. Yamada et al.  reported mass, asymmetries, and micro calcification in mammogram of DCIS. In our experience, ultrasonographic findings in DCIS were mottled/heterogeneous parenchyma with increased vascularity on Doppler, multiple intra cystic solid masses, and peripheral dilated ducts with irregular wall and echogenic contents. Watanabe T et al.  found that the most frequent ultrasonographic findings in DCIS were hypoechoic areas, followed by solid masses, abnormalities of the ducts or mixed masses, distortion, multiple small cysts, and echogenic foci without a hypoechoic area also were reported. The ultrasound features of DCIS have been described in the literature; however, the classifications vary slightly among authors. Ultrasound images of DCIS have been classified into masses, calcification alone, ductal change, and architectural distortion [16,17,18,19,20]. In our study, MRI findings of DCIS were retroareolar region of high signal intensity on T2WI, on dynamic post contrast study, diffuse non-mass enhancement with clustered ring pattern, segmental non-mass enhancement with clumped pattern, and regional non-mass enhancement. The extension of enhancement pattern was very close to the actual involvement of breast parenchyma by malignancy in correlation with pathology. So we found that MRI is valuable not only in diagnosis of DCIS but also for detection of actual extent of DCIS. Several reports [21, 22] found that DCIS most commonly appears as a non-mass enhancement (60–81%), and less frequently as a mass (14–41%) or a focus (1–12%). Nori et al.  compared the mean absolute error between preoperative MRI and mammography evaluations and final disease extent; MRI showed an improved accuracy of 51.2%. Study done by Hajaj et al  suggests that MRI could be an important tool in reducing the re-excision rates in the surgical management of high-grade DCIS.
In our experience, most of the infiltrating duct carcinoma cases were (IDC) associated with DCIS, and most cases were detected by mammogram and ultrasound, apart from few cases which were negative by mammogram due to dense parenchyma. Their appearance on US included irregular-shaped mass(es) with non-circumscribed margin and the remaining cases showed slight increase in echogenicity at the operative bed with nearby fluid collections and were categorized as BIRADS3 (postoperative change) as patients underwent unplanned resection for a mass. On MRI, all cases were detected, so MRI was valuable in detecting missed malignancy especially in dense parenchyma.
Bahl et al.  demonstrated that breast MRI is a valuable additional diagnostic tool in the setting of negative conventional imaging. In addition, a negative MRI in this symptomatic population may obviate the need for invasive surgery. Meta-analysis study done by Houssami et al.  reviewing 19 studies of women with breast cancer found that MRI detects additional disease in 16% of women. Regarding MRI feature of IDC with DCIS, all masses were irregular in shape with non-circumscribed margin and they showed either heterogeneous or rim enhancement with associated non-mass enhancement of clumped pattern on post contrast study. Apple et al.  concluded that invasive ductal carcinoma on post contrast study appeared as enhanced irregular shaped mass with non-circumscribed margin, or may appear as non-mass enhancement.
In our study, sensitivity and specificity of mammogram and ultrasound in diagnosing cases with pathologic nipple discharger was 71.4% and 54.2% respectively, while sensitivity and specificity of MRI was 100% and 83.3%. In a study done by Yılmaz R et al. , the sensitivity of US was found higher in the identification of intraductal lesions than that in the literature [20, 21]. This study revealed sensitivity and specificity for US as 75% and 66.7%, respectively. Ohlinger R et al.  reported a sensitivity of 82.9%, higher than study done by Yılmaz R et al. , but they calculated a specificity of 17.9%, which was lower than many studies. Ohlinger R et al.  study was multicentered, so it is difficult to standardize diagnostic criteria; this high rate of sensitivity could in part be due to broad positive findings (e.g., cystic lesions and ductal ectasia). Study done by Yılmaz R et al.  showed that US sensitivity and specificity can be higher if used specifically for ID pathologies and PND.
We can conclude that MRI add in diagnosis of different causes of pathologic nipple discharge and we believe it is mandatory in the following situations:
If there is intraductal echogenicity to confirm intraductal mass lesion and exclude inspissated secretion especially in young female to preserve duct system and to differentiate between benign from suspicious lesion.
In case of asymmetric heterogeneous breast parenchyma.
In suspicious breast mass to determine the extent of the lesion for proper selection of patient for conservative management.
Evaluation of residual suspicious lesion after improper operation.
Availability of data and materials
All data generated or analyzed during this study are included in this published article.
Breast Imaging-Reporting and Data System
Dynamic contrast enhanced
Ductal carcinoma in situ
Spontaneous pathologic nipple discharge
Yılmaz R, Bender O, Yabul FC et al (2017) Diagnosis of nipple discharge: value of magnetic resonance imaging and ultrasonography in comparison with ductoscopy. Balkan Med J 34:119–126
Ballesio L, Maggi C, Savelli S et al (2008) Role of breast magnetic resonance imaging (MRI) in patients with unilateral nipple discharge: preliminary study. Radiol Med 113:249–264
Lorenzon M, Zuiani C, Linda A et al (2011) Magnetic resonance imaging in patients with nipple discharge: should we recommend it? Eur Radiol 21:899–907
Zervoudis S, Iatrakis G, Economides P et al (2010) Nipple discharge screening. Womens Health (LondEngl) 6(1):135–151
Lubina N, Schedelbeck U, Roth A et al (2015) 3.0 Tesla breast magnetic resonance imaging in patients with nipple discharge when mammography and ultrasound fail. Eur Radiol 25:1285–1293
Patel BK, Falcon S, Drukteinis J (2015) Management of nipple discharge and the associated imaging findings. Am J Med 128:353–360
Bahl M, Baker JA, Green up RA et al (2015) Evaluation of pathologic nipple discharge: what is the added diagnostic value of MRI? Ann Surg Oncol 22:435–441
Paula IB, Campos AM (2017) Breast imaging in patients with nipple discharge. Radiol Bras 50(6):383–388
Chen L, Zhou WB, Zhao Y et al (2012) Bloody nipple discharge is a predictor of breast cancer risk: a meta-analysis. Breast Cancer Res Treat 132(1):9–14
Eiada R, Chong J, Kulkarni S et al (2012) Papillary lesions of the breast: MRI, ultrasound and mammographic appearances. AJR Am J Roentgenol 198:264–271
Dhull V, Sen J, Yadavet R et al (2016) Case series: imaging features of intraductal papillomas in patients presenting as nipple discharge. Int J Res Med Sci 4(7):2878–2882
Lam WWM, Chu WCW, Tang APY et al (2006) Role of radiologic features in the management of papillary lesions of the breast. Am J Roentgenol 186(5):1322–1327
Sarica O, Ozturk E, Demirkurek HC et al (2013) Comparison of ductoscopy, galactography, and imaging modalities for the evaluation of intraductal lesions: a critical review. Breast Care 8(5):348–354
Yamada T, Mori N, Watanabe M et al (2010) Radiologic-pathologic correlation of ductal carcinoma in situ. RadioGraphics 30:1183–1198
Watanabe T, Yamaguchi T, Tsunoda Y et al (2017) Ultrasound image classification of ductal carcinoma in situ (DCIS) of the breast: analysis of 705 DCIS lesions. Ultrasound Med Biol 43(5):918–925
Cho KR, Seo BK, Kim CH et al (2008) Non-calcified ductal carcinoma in situ: ultrasound and mammographic findings correlated with histological findings. Yonsei Med J 49:103–110
Mesurolle B, El-Khoury M, Khetani K et al (2009) Mammographically non-calcified ductal carcinoma in situ: sonographic features with pathological correlation in 35 patients. Clin Radiol 64:628–636
Mun HS, Shin HJ, Kim HH et al (2013) Screening-detected calcified and non-calcified ductal carcinoma in situ: differences in the imaging and histopathological features. Clin Radiol 68:27–35
Park JS, Park YM, Kim EK et al (2010) Sonographic findings of high-grade and non-high-grade ductal carcinoma in situ of the breast. J Ultrasound Med 29:1687–1697
Wang LC, Sullivan M, Du H et al (2013) Appearance of ductal carcinoma in situ. Radiographics 33:213–228
Ballard LJ, Ballard GR (2013) High-grade ductal carcinoma in situ: an overview for the radiologist. J Am Osteopath Coll Radiol 2:18–25
Greenwood HI, Heller SL, Kim S et al (2013) Ductal carcinoma in situ of the breasts: review of MR imaging features. Radiographics 33:1569–1588
Nori J, Meattini I, Giannotti E et al (2014) Role of preoperative breast MRI in ductal carcinoma in situ for prediction of the presence and assessment of the extent of occult invasive component. Breast J 20(3):243–248
Hajaj M, Karim A, Pascaline S et al (2017) Impact of MRI on high grade ductal carcinoma Insitu (HG DCIS) management, are we using the full scope of MRI? EJR 95:271–277
Houssami N, Ciatto S, Macaskill P et al (2008) Accuracy and surgical impact of magnetic resonance imaging in breast cancer staging: systematic review and meta-analysis in detection of multifocal and multicentric cancer. J Clin Oncol 26(19):3248–3258
Apple S, Bassett L, Poon C et al (2011) Invasive ductal carcinomas. In: Breast Imaging, 1st edn. Elsevier, Philadelphia. p 423
Ohlinger R, Stomps A, Paepke S et al (2014) Ductoscopic detection of Intraductal lesions in cases of pathologic nipple discharge in comparison with standard diagnostics: the German multicenter study. Oncol Res Treat 37:628–632
